AXIS C8110 Network Audio Bridge, Connects Analog Audio to Axis Network Audio, PoE, SIP, AXIS Audio Manager Edge, Black
Brand:
AXIS
AXIS C8110 Network Audio Bridge, Connects Analog Audio to Axis Network Audio, PoE, SIP, AXIS Audio Manager Edge, Black
€456.72 inc. VAT
02370-001
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
AXIS C8110 Network Audio Bridge — Join Analog Audio and Axis Network Audio
Analog ↔ network audioPoE poweredSIP + AXIS Audio Manager Edge5-year Axis warranty
The AXIS C8110 Network Audio Bridge connects analog audio equipment to an Axis network audio system in both directions. It is for integrators and facility teams who want to feed a microphone, music player or existing paging source into Axis IP speakers — or send network audio and SIP announcements into an existing analog amplifier and speaker installation.
The bridge is powered by PoE (IEEE 802.3af Class 2) or 8–28 V DC, has mic/line inputs and line outputs, two supervised configurable I/Os for buttons or relays, and built-in AXIS Audio Manager Edge for managing up to 200 speakers in 20 zones with schedules and priorities. SIP support lets it work with Cisco, Asterisk and other PBX systems.
Before you order: It is not an amplifier: the line output needs an external amplifier to drive passive speakers. Mic and line input share one 3.5 mm jack, so there are no XLR or multiple mic inputs.
What's in the Box
- AXIS C8110 Network Audio Bridge
- Power connector (DC terminal block)
- I/O connector
- Hook-and-loop fastener
- AVHS authentication key
- Installation guide
- No power supply — PoE or an optional DC supply is required
What It Means in Practice
- Add background music or live announcements from an analog mixer to a zone of Axis network speakers across a building.
- Bring an existing analog PA amplifier into a modern IP audio system, so new SIP/IP announcements also play on legacy speakers.
- Connect a push-to-talk button or relay to the supervised I/O ports to trigger messages or mute zones.
- AXIS Audio Manager Edge runs on the device itself — no separate server needed for up to 200 speakers in 20 zones.
- Compact (24 × 56 × 128 mm, 107 g) with hook-and-loop fastening, so it hides behind a rack shelf or mixer.
What Will Not Work
- Cannot drive passive speakers directly — no built-in amplifier.
- No balanced XLR inputs or multi-channel mixing.
- Indoor only (IP20); not for outdoor installation.
- Network port is 10/100 Mbps (sufficient for audio, not a switch replacement).
Key Features
Two-way bridge
Analog to network and network to analog audio.
AXIS Audio Manager Edge
Zones, scheduling, priorities and health monitoring built in.
SIP ready
Peer-to-peer or PBX, SRTP/SIPS/TLS, DTMF.
Secure
Axis Edge Vault, secure boot, encrypted microSD storage.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The C8110 is the glue between an old PA system and a new Axis IP audio network — great value when you want to keep existing amplifiers or add a live source to IP speakers. Remember it needs an amplifier for passive speakers. More surveillance and IP audio hardware in our IP cameras section.
✓ Buy it if you need to connect analog audio sources or amplifiers to Axis network speakers or SIP paging.
✕ Skip it if you need an amplifier, XLR inputs or an outdoor-rated unit.
→ Also consider Axis network speakers to build out IP audio zones.
Tell us your existing amplifier, speakers and PBX and we will confirm the C8110 fits before you order.
Features - AXIS - 02370-001
Colour
black
More Details
Product Code
CD92330
EAN Code
7331021076518
Manufacturer
AXIS
