ICY BOX IB-2925MS-CU31 Club Case — 4-Bay USB-C Enclosure for 2× M.2 SSD and 2× 2.5"/3.5" SATA Drives
4 bays: 2× M.2 + 2× SATAUSB 3.2 Gen 2 · 10GbpsNVMe & SATA M.2Aluminium · 12V/4A PSU
The ICY BOX IB-2925MS-CU31 Club Case is a 4-bay external enclosure that takes two M.2 SSDs (NVMe or SATA) and two 2.5" or 3.5" SATA hard drives or SSDs at the same time, all connected to the computer through one USB 3.2 Gen 2 (10Gbps) USB-C port. It is built for people who keep several drives in use — photo and video archives, backup sets, project disks — and want them in one aluminium box on the desk instead of a pile of single enclosures.
Each drive appears to the computer as its own disk, with its own power switch and power/activity LEDs, so you can switch off the bays you are not using. The M.2 slots accept 2230 to 22110 modules with M-key or B+M-key, up to 4TB each; the SATA bays take drives up to 20TB each. A 12V/4A power supply is included, so 3.5" hard drives run without extra power.
Before you order: All four drives share one 10Gbps USB link — fast NVMe SSDs will not reach their internal speed, and RAID, cloning or JBOD spanning are not provided by the enclosure. Connect to a USB 3.2 Gen 2 (10Gbps) port for full speed.
What's in the Box
- ICY BOX IB-2925MS-CU31 Club Case enclosure
- USB-C to USB-C and USB-C to USB-A cable, 40 cm
- Power supply 12V / 4A (48W), 150 cm lead
- Manual
What It Means in Practice
- Mount two M.2 SSDs and two 3.5" HDDs in one box — e.g. fast SSDs for active projects and large HDDs for archive.
- Each drive is independent: format, eject or power-off one bay without touching the others.
- Works with USB-C and USB-A ports thanks to the included dual cable; Gen 1 or USB 2.0 ports reduce speed.
- Ideal for copying between drives inside the box, migrating data or reading old drives from retired PCs.
What Will Not Work
- Hardware RAID, mirroring or one-touch cloning — use your operating system or backup software instead.
- Full native NVMe speed — the shared 10Gbps link limits throughput to roughly USB 3.2 Gen 2 rates.
- PCIe M.2 cards with other keys (e.g. Wi-Fi A+E key) or mSATA/U.2 drives.
- Running without the power supply — the enclosure needs its 12V adapter.
Key Features
Mixed 4-bay layout
2× M.2 (NVMe or SATA, 2230–22110) plus 2× 2.5"/3.5" SATA bays usable simultaneously.
USB 3.2 Gen 2 with UASP
One 10Gbps USB-C link with UASP; VL822 hub with JMS581DL and JMS580 bridges.
Per-drive control
Separate power switch and power/activity LED for each drive.
Aluminium housing
Black aluminium enclosure with non-slip feet; 142 × 57 × 115 mm.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
A multi-bay box like this is the tidiest way to keep mixed SSDs and HDDs online for backup and archive work — just remember all bays share one 10Gbps link, so it is about capacity and convenience rather than peak NVMe speed. More single and multi-bay options are in our HDD/SSD enclosures.
✓ Buy it if you want two M.2 SSDs and two SATA drives connected through one USB-C cable, each as its own disk.
✕ Skip it if you need hardware RAID, a NAS on the network, or full NVMe speed from a single drive.
→ Also consider a single M.2 NVMe USB 3.2 Gen 2x2 enclosure for maximum speed, or a NAS for shared network storage.
Not sure your drives fit? Send us the drive models and we will confirm compatibility before you order.
Features - Icy Box - IB-2925MS-CU31
Colour
black
Interface
- USB Type-C
More Details
Product Code
04:601043
EAN Code
4250078175520
Manufacturer
Icy Box
