Cisco ATA 192 Multiplatform Analog Telephone Adapter / VoIP phone adapter / 2 ports / 100Mb LAN | ATA192-3PW-K9
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | VoIP phone adapter |
| Width | 10 cm |
| Depth | 10 cm |
| Height | 2.8 cm |
| Weight | 132.1 g |
| Networking | Networking |
| Form Factor | External |
| Ports Qty | 2 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet |
| Network / Transport Protocol | TCP/IP, PPTP, UDP/IP, L2TP, IPSec, PPPoE, ARP, RTP, RTCP |
| Remote Management Protocol | SNMP 3, HTTP, HTTPS, TFTP, SSH, TR-069 |
| Status Indicators | Power, phone, Internet |
| Features | NAT support, Syslog support, DiffServ support, IPv6 support, SNTP support, wall mountable, port forwarding, reset button, LLDP support, DHCP client, Automated Attendant (IVR), Type of Service (ToS), Internet Control Message Protocol (ICMP), dual image support, Cisco Discovery Protocol |
| Encryption Algorithm | AES, TLS 1.1, TLS 1.2, ESP |
| Authentication Method | Secure Shell (SSH) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ab (LLDP) |
| IP Telephony | IP Telephony |
| VoIP Protocols | SIP, RTCP, RTP, SRTP |
| Voice Codecs | G.711, G.729a, G.729ab, G.711a, G.726, T.38, G.711µ |
| Telephony Interfaces | 2 phone (FXS) |
| IP Telephony Features | Call forwarding, Caller ID, call waiting, call hold, distinctive ringing, call transfer, Do-not-disturb (DND) support, caller ID block/unblock |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 2 x FXS - RJ-11 ¦ 2 x 100Base-TX - RJ-45 |
| Miscellaneous | Miscellaneous |
| MTBF | 300,000 hours |
| Compliant Standards | FCC Part 15 B, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, IEC 60950-1:2005 Second Edition, EN 61000-3-3:2013, EN 55024:2010+A1:2015, Directive 2014/35/EU, Directive 2014/30/EU, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, ANSI C63.4-2014, AS/NZS 60950-1:2015, ICES-003:2016, EN 61000-3-2:2014 Class A, EN 55032:2015 Class B, AS/NZS CISPR32:2015 Class B, CISPR 32:2015 Class B |
| Power | Power |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V / DC 5 V (50/60 Hz) |
| Power Consumption Operational | 5 Watt |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 1 year |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - Cisco - ATA192-3PW-K9
More Details
Product Code
677NK34
EAN Code
0889728031639
Manufacturer
Cisco
