Cisco Catalyst 9200 2 x 25GE Network Module (C9200-NM-2Y=)
2 × SFP28 25GHot-swappableC9200-24PXG / 48PXG onlySpare part
The Cisco C9200-NM-2Y= is the Catalyst 9200 2 x 25GE network module: an uplink module with two SFP28 slots that gives a modular Catalyst 9200 multigigabit switch 25G uplinks to the core or distribution layer.
It is meant for networks running C9200-24PXG or C9200-48PXG switches, where multigigabit access ports for Wi-Fi 6/6E access points need more uplink bandwidth than 10G.
Before you order: This module works ONLY in the Catalyst C9200-24PXG and C9200-48PXG. It does not fit other C9200 models (24T/48T/24P/48P etc.), and C9200L / C9200CX have fixed uplinks with no module slot. Minimum software: Cisco IOS XE 17.1.1.
What's in the Box
- 1 × Cisco C9200-NM-2Y network module
- No SFP28 transceivers or cables — order optics separately
What It Means in Practice
- Two 25G uplinks give up to 50 Gbps towards the core, matching the load of many multigigabit access points.
- The module is hot-swappable (OIR): Cisco asks you to wait 6–8 seconds between removal and insertion and to insert it without cables or transceivers attached.
- Port speed follows the optic installed, so plan SFP28 optics or DAC cables that match the device on the other end.
- Use Cisco-supported optics from the Cisco transceiver compatibility matrix.
What Will Not Work
- It will not work in a C9200-24P, C9200-48P, C9200-24T or any other non-PXG Catalyst 9200.
- It does not fit Catalyst 9200L, 9200CX, 9300 or 9300X switches.
- Cisco does not publish 1G/10G operation for this module — if your core is 10G, the C9200-NM-4X= 4 × 10G module is the safer choice.
- Transceivers are not included.
Key Features
25G uplinks
Two SFP28 slots for 25 Gigabit uplinks from the access layer.
Hot-swappable
Online insertion and removal, so the switch keeps running while the module is changed.
Built for multigigabit access
Pairs with C9200-24PXG/48PXG multigigabit ports for Wi-Fi 6/6E access points.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The right uplink module when a C9200-24PXG or 48PXG is feeding many multigigabit Wi-Fi access points and 10G uplinks become the bottleneck. On any other 9200 it simply will not work, so check the model on the switch label first. Browse our network switches for matching switches.
✓ Buy it if you run a C9200-24PXG or C9200-48PXG and need 25G uplinks.
✕ Skip it if your switch is any other C9200 or C9200L model, or your core is 10G only.
→ Also consider C9200-NM-4X= for 4 × 10G SFP+ uplinks on all modular C9200 models.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
