Cisco C9400-PWR-3200AC= — 3200 W AC Power Supply for Catalyst 9400 Chassis
3200 W at 200–240 V ACPlatinum ratedHot-swappableC9404R / C9407R / C9410R
The Cisco C9400-PWR-3200AC= is the 3200 W AC power supply module (spare) for Cisco Catalyst 9400 Series modular switches — the C9404R, C9407R and C9410R chassis — used to replace a failed unit, add N+1 or N+N redundancy, or raise the power available to line cards and PoE.
On 200–240 V AC it delivers 3200 W; on 100–120 V AC the output drops to 1570 W. The module is Platinum rated, hot-swappable, self-cooled, and has a front on/off switch, release latch and cord-retention mechanism. It requires an IEC C19 power cord rated 16 A (or 20 A, depending on country).
Before you order: Needs a C19 power cord and a 16 A circuit — a standard C13 kettle cord or 10 A outlet will not work. In Cyprus/EU, Cisco lists cords such as CAB-CEE77-C19-EU and CAB-I309-C19-INTL; the UPS cord is CAB-C19-CBN.
What's in the Box
- Cisco C9400-PWR-3200AC= power supply module
- Power cord: not stated as included — Cisco sells C19 cords as separate part numbers; tell us your socket type and we quote the right one
What It Means in Practice
- Plan on 230 V: in Cyprus and Europe the full 3200 W is available, while on a 110 V feed the same module gives only 1570 W.
- Add modules for N+1 redundancy (one spare) or N+N (separate power grids A and B) — chassis bays: 4 on C9404R, 8 on C9407R and C9410R.
- Each module needs its own 16 A feed: check your rack PDU outlets (C19) and circuit breakers before ordering several units.
- Hot-swappable: replace a failed module while the switch keeps running on the remaining supplies.
- Requires Cisco IOS XE 16.6.1 or later on the chassis.
What Will Not Work
- Will not fit Catalyst 9300, 9200 or 9500/9600 switches.
- Will not run from a C13/10 A cord or a standard office power strip.
- No DC input — for -48 V DC sites use a Cisco DC module.
- On 100–120 V it cannot deliver 3200 W (only 1570 W).
Key Features
3200 W output
Full output on 200–240 V AC for dense PoE and line-card loads.
Redundancy modes
Supports N+1 and N+N (combined mode also available).
Hot-swappable
Front on/off switch, release latch and cord retention.
Platinum rated
High-efficiency AC conversion, power factor ≥0.95 at full load.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The C9400-PWR-3200AC= is straightforward when the electrical side is right: 230 V, a C19 cord and a dedicated 16 A feed per module. Get those three right and the module simply slots in. More switching hardware in our network switches section.
✓ Buy it if you run a Catalyst 9404R, 9407R or 9410R and need a replacement or extra redundancy.
✕ Skip it if you do not have C19/16 A outlets, or your switch is not a Catalyst 9400 chassis.
→ Also consider matching CAB-CEE77-C19-EU or CAB-C19-CBN power cords.
Send us your Catalyst 9400 chassis model, line cards and PoE load and we will size the power supplies and cords before you order.
