Cisco NXA-PAC-650W-PI= — Nexus 650W AC Power Supply, Port-Side Intake Airflow
650W AC80 PLUS PlatinumPort-Side IntakeHot-swap
The Cisco NXA-PAC-650W-PI= is a 650 W AC hot-swappable power supply with port-side intake airflow for Cisco Nexus 9300 and Nexus 3000 data-centre switches, supplied as a spare (=) part for replacement or for adding 1+1 redundancy.
It delivers 12 VDC main and 12 VDC standby power at 80 PLUS Platinum efficiency, accepts 100–240 VAC (50–60 Hz) and is colour-coded burgundy so the airflow direction is visible at a glance. With this direction the switch ports face the cold aisle (air enters on the port side).
Before you order: All power supplies and fan modules in a Nexus switch must use the SAME airflow direction. If your switch has blue (port-side exhaust) fans or PSUs, you need the NXA-PAC-650W-PE= (port-side exhaust, blue) instead — mixing directions can overheat and shut down the switch. Do not mix AC and DC PSUs.
What's in the Box
- Cisco NXA-PAC-650W-PI= 650 W AC power supply module
- Power cord: not specified by Cisco for the spare — tell us your PDU/socket type and we will supply the right cord
What It Means in Practice
- Replace a failed PSU while the switch runs on the second one — no downtime.
- Add the second PSU to a single-PSU switch for 1+1 redundancy and connect each to a separate feed.
- Match the burgundy colour of your existing fans and PSU before ordering.
What Will Not Work
- Switches whose fans use the opposite airflow direction — order NXA-PAC-650W-PE= (port-side exhaust, blue).
- Nexus 93180YC-EX fully populated with 5 W+ optics on all 36 ports — Cisco requires the 1100 W PSU there.
- Nexus models not on the compatibility list, Catalyst switches, servers or PCs.
Key Features
80 PLUS Platinum
Climate Savers Platinum efficiency.
Port-Side Intake airflow
Colour-coded burgundy handle for quick identification.
Hot-swap
Replace during operation; 1+1 redundancy with two PSUs.
Wide input
100–240 VAC nominal (90–132 / 180–264 VAC), 47–63 Hz.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
For a Nexus switch the only real decision is airflow: match the burgundy colour of what is already installed and you have the right part. Keep a spare on the shelf for critical switches. More in our switches section.
✓ Buy it if your Nexus switch uses port-side intake (burgundy) fans and needs a replacement or redundant PSU.
✕ Skip it if your fans are the opposite colour or you run a 93180YC-EX fully loaded with high-power optics.
→ Also consider NXA-PAC-650W-PE= (port-side exhaust, blue) for opposite airflow.
Send us your switch model and a photo of the fan/PSU colour and we will confirm the correct part before you order.
