Cisco Aironet Outdoor Power Injector — 60 W
60 WOutdoorIP66802.3at
The Cisco AIR-PWRINJ-60RGD2= is a rugged outdoor power injector that delivers up to 60 W over the network cable to an outdoor access point or other powered device. It takes 90–264 V AC and outputs 55 V DC at up to 2 A, supports IEEE 802.3af and 802.3at, and sits in an IP66, NEMA 4X housing rated −40 to 55 °C. It weighs 1.35 kg and measures 214 × 150 × 70 mm. The RGD2 version comes with an unterminated three-wire AC cable, so it is wired by an electrician to the local supply. Cisco files it under its Aironet 1570 outdoor access point documentation. In practice it powers an outdoor AP on a pole or wall where no PoE switch is nearby.
Compatibility — check before buying:
The mains cable has no plug — it must be wired by a qualified electrician. The RGD1 version has a US NEMA 5-15P plug and does not suit Cyprus sockets. Use shielded CAT5e or better on the input and shielded outdoor-rated CAT5e or better on the output, 0.20–0.35 in in diameter for the waterproof glands. The pole-mount kit (AIR-PWRINJ-60-PMK=) is sold separately. Not sure? Tell us your model and we check it for you.
Best For
✓ Outdoor Aironet access points
✓ Pole and wall installs
✓ Campus and yard Wi-Fi
✓ Sites without outdoor PoE switches
✓ Harsh weather locations
✓ Replacing an outdoor injector
Key Features
60 W outdoor PoE
55 V DC, 802.3af/at.
Weatherproof
IP66, NEMA 4X, −40 to 55 °C.
Hard-wired AC
Unterminated cable, no US plug.
Waterproof plugs
Two sealed RJ45 connectors included.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Mount the injector close to the access point and keep the mains connection inside a proper outdoor junction box. For access points, see our access points.
Buyer’s Guide
Buy it if
You need 60 W PoE outdoors for an access point.
Skip it if
You want a plug-in indoor injector.
Also consider
Cisco AIR-PWRINJ-60-PMK= pole-mount kit.
Features - Cisco - AIR-PWRINJ-60RGD2=
More Details
Product Code
677HW12
EAN Code
0882658905315
Manufacturer
Cisco
