Datalogic Gryphon GM4500 Wireless 1D/2D Barcode Scanner USB Kit, 433 MHz STAR, Charging Base and Cable, Black

Brand:
Datalogic
Datalogic Gryphon GM4500 433 MHz USB Scanner Kit Black
Datalogic Gryphon GM4500 Wireless 1D/2D Barcode Scanner USB Kit, 433 MHz STAR, Charging Base and Cable, Black
€386.81 inc. VAT
Buy
GM4500-BK-433K1
€325.05
€386.81 inc. VAT
Ships from EU stock: 20 item(s)
+ −
Add to wish list Ask a question
Product Code
03:281202
EAN Code
4060533233487
Manufacturer
Datalogic
Features
Wireless

Quick Specs

Connection
STAR 433 MHz · USB kit
Capture
1D / 2D · 1280 × 800
Battery
3250 mAh · inductive charging
Protection
IP52 · 1.8 m drop
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

GM4500: cordless scanning through a dedicated STAR base

433 MHz STAR1D / 2DInductive chargingUSB kit

The black Datalogic GM4500-BK-433K1 is a cordless 1D/2D imager kit for checkout, picking and general business data entry. It includes one scanner, a WLC4090-BK-433 radio/charging base and USB cable 90A052258. The scanner talks to the base over 433 MHz STAR radio; the base connects by USB to the host application. It is not the GBT Bluetooth version and does not pair directly with a phone as a Bluetooth keyboard.

Before you order:
A host computer or POS with a suitable receiving application is required. USB is supplied; RS-232 requires the correct separate cable. The quoted 4-hour charge time uses external 12 V power; an external power supply is not confirmed as part of this kit.

What's in the Box

  • 1 × black GM4500 scanner.
  • 1 × WLC4090-BK-433 base.
  • 1 × USB cable 90A052258.

What It Means in Practice

  • Connect the base to the host, link the scanner and set the host/keyboard format with Aladdin or programming barcodes. Test a scan inside the target application.
  • Walk to a nearby bulky item, scan its label and return the reader to the cradle for contactless charging. The host application handles prices or stock updates.
  • The 50 m radio figure is an open-air reference, not the optical reading distance. For example, the stated QR 10 mil range is 5.5–24.0 cm.

What Will Not Work

  • This is not a Bluetooth or Wi-Fi scanner and is not a standalone inventory terminal.
  • HD optics, Digimarc red-illumination and healthcare variants are separate configurations.

Key Features


STAR radio link
Two-way 433.92 MHz communications support point-to-point or configured multipoint systems, up to 16 readers per receiver.

Contactless charging
Inductive battery charging removes exposed charging contacts. The adjustable WLC4090 supports scan-while-charging use.

Visible read confirmation
The Green Spot on the code, dual LEDs and adjustable beeper help confirm successful capture.

Megapixel reading
A 1280 × 800 sensor, warm white illumination and red cross aimer support printed and mobile-screen codes.

Technical Specifications

Identity and package
MPN GM4500-BK-433K1
EAN 4060533233487
Package 1 × GM4500 scanner; 1 × WLC4090-BK-433 base; 1 × USB cable 90A052258
Colour Black
Wireless and host
Radio Datalogic STAR Cordless System, 433.92 MHz
Radiated power Less than 6.3 mW
Radio range Up to 50 m in open air; site conditions affect range
Configurations Point-to-point; multipoint up to 16 readers per receiver; two-way communication
Base interfaces WLC4090: USB / RS-232; USB cable supplied
Capture
Sensor 1280 × 800 pixels, 1 MP
Aiming 650 nm red laser, 4-dot pattern with centre cross
Illumination Warm white
Motion tolerance 35 in/s
Minimum contrast 15%
Pitch / skew / roll ±65° / ±65° / 360°
1D Standard 1D codes including GS1 DataBar
2D Aztec, Han Xin, Data Matrix, MaxiCode, Micro QR, QR, Dot Code
Postal Australian Post, British Post, China Post, IMB, Japanese Post, KIX, Planet, Postnet, RM4SCC
Stacked / composite EAN/JAN Composites, GS1 DataBar Composites, Expanded Stacked, Stacked, Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/E Composites
Image output BMP, JPEG, TIFF; 256, 16, 2 greyscale levels
SR minimum resolution 1D: 4 mil; PDF417: 5 mil; Data Matrix: 7.5 mil
Read confirmation Adjustable beeper; 3GL Green Spot and two good-read LEDs
Mode sensing Motionix motion sensing; scan while charging in adjustable cradle
Typical SR ranges
Code 39, 5 mil 7.0–38.0 cm
Code 39, 10 mil 2.2–58.0 cm
Data Matrix, 10 mil 5.5–27.0 cm
Data Matrix, 15 mil 2.8–41.0 cm
EAN / UPC, 13 mil 1.0–71.0 cm
PDF417, 10 mil 2.5–41.0 cm
QR, 10 mil 5.5–24.0 cm
Range conditions Typical; minimum depends on symbol length and scan angle; printing, contrast and ambient light affect results
Power and battery
Battery Lithium-ion, 3250 mAh
Reads per charge Up to 80000, manufacturer reference; actual use varies
Charge time 4 hours with external 12 V DC; not a USB-charge time guarantee
Charging Inductive, no charging contacts
Base input 4.5–14 V DC ±5%
Power / current Charging less than 6 W typical; scanner 330 mA at 3.7 V; cradle 80 mA at 5 V operative
Charge LEDs Flashing orange: charging; steady green: charged
Physical and environment
Dimensions 166 × 68 × 109 mm
Weight 235 g including battery
Sealing IP52
Drop Repeated 1.8 m drops onto concrete
Ambient light 0–100000 lux
ESD air discharge 16 kV
Humidity 0–95%, non-condensing
Operating temperature 0°C to +50°C
Storage temperature −40°C to +70°C
Laser class IEC 60825 Class 2; do not stare into beam
Environmental compliance EU RoHS, China RoHS
Utilities Datalogic Aladdin, OPOS / JavaPOS, Remote Host Download
Manufacturer warranty 3-year cordless factory warranty, subject to Datalogic terms; seller terms separate

Frequently Asked Questions

Can it pair directly with an iPad over Bluetooth?
No. This GM model uses STAR radio to its matching 433 MHz base. The GBT series is the Bluetooth alternative.
Is 50 m the barcode reading range?
No. It is the maximum open-air radio range. Optical distance depends on barcode type, size and conditions.
Does USB guarantee a 4-hour full charge?
No. The manufacturer specifies 4 hours using external 12 V DC power; USB charging conditions can differ.
Singular Expert Insight
Choose this kit for a fixed host that needs cordless reach around the counter. Check the real radio environment and charging arrangement rather than treating maximum figures as everyday guarantees. Compare scanner formats here: Barcode scanners at Singular

Buyer’s Guide

✓

Buy it if

 you want cordless 1D/2D scanning through a supplied USB radio base.
✕

Skip it if

 you need direct Bluetooth pairing, Wi-Fi or a self-contained mobile terminal.
→

Also consider

 a GBT Bluetooth configuration or a wired reader, according to the host and workflow.
Confirm host interface, radio environment and power requirements with Singular.
