Datalogic USB Cable Type A with External Power Input, 4.5 m (15 ft), for Magellan 3450VSi and 3550HSi Scanners
Brand:
Datalogic
Datalogic USB Cable Type A with External Power Input, 4.5 m (15 ft), for Magellan 3450VSi and 3550HSi Scanners
€24.89 inc. VAT
90A052292
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Datalogic 90A052292 USB Type A Cable with External Power, 4.5 m, for Magellan 3450VSi / 3550HSi
USB Type AExternal power input4.5 m / 15 ftMagellan 34xx/35xx
The Datalogic 90A052292 is a 4.5 m (15 ft) USB Type A interface cable with an external power input, made for the Magellan 3450VSi vertical and Magellan 3550HSi horizontal on-counter scanners.
Datalogic lists it for both families as the USB cable for installations where the scanner should be powered from its own power supply rather than from the POS terminal, and where the terminal sits some distance from the checkout counter.
Before you order: This cable takes power from an external Datalogic power supply, which is not included. If your scanner currently runs only from the terminal's USB port, you either need that supply or a power-off-terminal USB cable instead.
What's in the Box
- 1 × Datalogic USB Type A cable with external power input, 4.5 m (90A052292)
What It Means in Practice
- The USB-A end goes into the POS terminal or PC; the scanner end plugs into the host port under the Magellan.
- Power for the scanner comes from a separate power supply plugged into the cable, so a heavily loaded terminal USB port does not have to feed the scanner.
- 4.5 m lets you route the cable under the counter or through a cable tray to a terminal that sits back from the checkout.
- Works with the standard Magellan USB modes (USB keyboard or USB-COM) selected on the scanner.
What Will Not Work
- It will not power the scanner without the separate power supply connected to the cable.
- Magellan 9300i/9400i/9800i bioptic scanners and the smaller Magellan 1100i/1500i use their own cable lists — do not order this for them.
- IBM POS terminals that expect IBM USB (powered USB / Port 9B, 17) need Datalogic's IBM USB cables instead.
- RS-232 hosts — Datalogic lists separate RS-232 cables for these scanners.
Key Features
Separate power path
Keeps scanner power independent of the terminal's USB budget, useful on POS PCs with many peripherals.
Counter-length cable
15 ft covers most checkout layouts without an extension.
Listed for two families
One cable for both Magellan 3450VSi and 3550HSi, so mixed lanes can share spares.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
On busy checkout lanes the external-power cable avoids a common failure: a scanner that drops out when the terminal's USB port is shared with a printer, cash drawer and display. Order it together with the correct power supply, and if you also need network patch leads for the lane, see our cables range.
✓ Buy it if Buy it if you run a Magellan 3450VSi or 3550HSi on USB and want the scanner powered from its own supply, with the terminal up to 4.5 m away.
✕ Skip it if Skip it if you want the scanner powered directly from the terminal — choose a power-off-terminal USB cable instead.
→ Also consider Also consider Datalogic 8-0754-12 (USB Type A, power off terminal, 2 m) or 90A052392 (USB Type A, external power, 10 ft).
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
Features - Datalogic - 90A052292
Length
5m
More Details
Product Code
V384073
EAN Code
5706998324030
Manufacturer
Datalogic
