Digitus 100 Gbps QSFP28 to QSFP28 Active Optical Cable (AOC), 4 × 25G, 850 nm, Hot-Pluggable, 10m
Brand:
Digitus
Digitus 100 Gbps QSFP28 to QSFP28 Active Optical Cable (AOC), 4 × 25G, 850 nm, Hot-Pluggable, 10m
€431.52 inc. VAT
DN-81626
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Digitus 100 Gbps QSFP28 Active Optical Cable (AOC), 10 m
100G · QSFP28 to QSFP2810 m active optical4 × 25G lanes · 850 nmHot-pluggable
The Digitus DN-81626 is a 100 Gbps QSFP28 active optical cable, 10 m long, with a QSFP28 module fixed at each end. It connects two 100G QSFP28 ports — switch to switch or switch to server — across a row of racks without separate transceivers or patch cords.
Inside, four full-duplex channels run at up to 25.78/28.05 Gb/s each (103.1 Gb/s aggregate) over multimode fibre, driven by an 850 nm VCSEL array with PIN photodetectors. It runs from the port’s 3.3 V supply at under 3.5 W and is hot-pluggable.
Before you order: Digitus lists compatibility with switches from Cisco, Dell, Juniper, Huawei, Extreme and others, but some vendors lock their QSFP28 ports to their own coded optics. Send us the switch model and software version before ordering and we will confirm.
What's in the Box
- 1 × Digitus DN-81626 QSFP28 active optical cable, 10 m, ends factory-attached
What It Means in Practice
- Ten metres covers links across a row of racks — longer than a passive copper DAC can manage at 100G.
- No transceivers to buy separately and no fibre end faces to clean at installation.
- Thin, light fibre cable is easier to route through cable managers than thick copper DACs.
- The case temperature range is 0 °C to +70 °C — a standard data-centre rating.
What Will Not Work
- QSFP+ (40G) ports or SFP28 (25G) ports — it is 100G QSFP28 on both ends.
- Links longer than 10 m: the length is fixed.
- Breakout to 4 × 25G: this is a straight QSFP28-to-QSFP28 cable.
- Switches that reject third-party optics.
Key Features
100G QSFP28
Four 25G lanes, 103.1 Gb/s aggregate, QSFP28 MSA form factor on both ends.
Active optical
850 nm VCSEL array with PIN photodetector array over multimode fibre.
Low power
3.3 V supply, under 3.5 W.
Hot-pluggable
Insert and remove with the switch running.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
For a 10 m 100G link the DN-81626 avoids buying two QSFP28 transceivers and an MPO cord. The one thing to confirm is that your switches accept third-party optics. For the switches themselves, see our network switches.
✓ Buy it if you need a 10 m 100G QSFP28-to-QSFP28 link between switches that accept third-party cables.
✕ Skip it if your ports are 40G QSFP+ or 25G SFP28, or the switch only accepts its own coded optics.
→ Also consider A pair of QSFP28 SR4 transceivers with an MPO cord if you need a longer or reconfigurable link.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
Features - Digitus - DN-81626
Length
10m
More Details
Product Code
04:419513
EAN Code
4016032480990
Manufacturer
Digitus
