DIGITUS - 25GBase direct attach cable - SFP28 (M) to SFP28 (M) - 3 m - shielded twinaxial - SFF-8432 - passive | DN-81243
DIGITUS - 25GBase direct attach cable - SFP28 (M) to SFP28 (M) - 3 m - shielded twinaxial - SFF-8432 - passive | DN-81243
€63.02 inc. VAT
DN-81243
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
· Transmission channels: RX and TX· Connections: SFP28
· data rates of up to 25.88 Gbps supported
· Temperature range: 0 to 70°C
· Storage temperature range: -40 to 85°C
· Power: +3.3 V supply voltage
· Power consumption: 0.5 W
· Compatible with MSA SFP28
· Electrical interface: 20-pole connector plug
· Management interface: Serial, I²C
· The connection is compatible with the SFF-8432 specification
· Compatible with the following manufacturers: Allnet, CISCO, 3COM, D-LINK, Dell, Edimax, Etherwan, ENTERASYS, EXTREME, FINISAR, FORCE 10, Fortinet, HUAWEI, IBM, JUNIPER, LINKSYS, NETGEAR, NORTEL, RIVERSTONE, ZTE, ZYXEL
Special Fetures
· 3 m maximum distance· AWG 30 Twinax Cable
· data rates of up to 25.88 Gbps supported
· Hot-plug capable SFP 20 PIN connection
· Temperature range: 0 to 70°C
· Improved pluggable form factor (IPF)
· Power: +3.3 V supply voltage
· Compatible with the SFF-8432 specifications
Product Specification
| Network Cable Type | 25GBase direct attach cable - SFF-8432 |
| Technology | Shielded twinaxial |
| Features | Passive cable, Improved Pluggable FormFactor (IPF) compliant |
| Length | 3 m |
| Connectivity | |
| Connector | SFP28 - male |
| Connector (Second End) | SFP28 - male |
| Miscellaneous | |
| Compliant Standards | MSA |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 26 cm |
| Shipping Depth | 26 cm |
| Shipping Height | 4 cm |
| Shipping Weight | 150 g |
| Manufacturer Warranty | |
| Service & Support | 5-year warranty |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
Features - Digitus - DN-81243
Length
3m
More Details
Product Code
04:419511
EAN Code
4016032478805
Manufacturer
Digitus
