Equip Cat5e Unshielded Junction Box, LSA/IDC Punch-Down, T568A/B, 22–26 AWG, for Extending or Repairing Cable Runs, White
Brand:
Equip
Equip Cat5e Unshielded Junction Box, LSA/IDC Punch-Down, T568A/B, 22–26 AWG, for Extending or Repairing Cable Runs, White
€4.64 inc. VAT
135410
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Equip Cat5e Unshielded Junction Box — LSA Punch-Down, White
Cat5eUnshieldedLSA / IDC22–26 AWG
The Equip 135410 is an unshielded Cat5e junction box with LSA/IDC punch-down terminals on both sides, for joining two solid installation cables directly — the usual way to extend a run that is too short or repair a cable that was cut, without adding plugs or couplers.
Each cable end is punched down on colour-coded T568A/T568B terminals and the box is closed. Because there are no RJ45 connections in between, the joint is permanent and stable, which is what you want inside a wall, ceiling or trunking. Equip rates the terminals for up to 200 punch operations.
Before you order: You need an LSA punch-down tool to terminate the wires — it is not included. The box suits unshielded U/UTP solid installation cable, 22–26 AWG.
What's in the Box
- 1 × Equip Cat5e unshielded junction box (135410)
What It Means in Practice
- Repairs a damaged cable or extends a short run in place, instead of pulling a new cable.
- No plugs or couplers in the path, so the joint is as reliable as the cable itself.
- Colour-coded T568A and T568B terminals reduce wiring errors.
- Re-terminable up to 200 times.
What Will Not Work
- No RJ45 sockets — patch cords cannot be plugged in. For that use an inline or keystone coupler.
- Punch-down tool not included.
- Not rated for Cat6 or 10GBase-T — the box is Cat5e.
- No mounting accessories are listed by Equip.
Key Features
Plug-free joint
Two cables are joined directly on LSA terminals.
T568A / T568B coded
Colour codes for both wiring schemes.
Durable terminals
Up to 200 punch operations.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
A junction box is the professional repair for a cut or short installation cable: it keeps the link permanent and plug-free, as long as the box category matches the cable. Use patch cables of at least the same category on both sides.
✓ Buy it if You need to extend or repair a Cat5e installation cable inside a wall, ceiling or trunking.
✕ Skip it if You want to join patch cords, or the cabling is Cat6A — choose a coupler or a Cat6A junction box.
→ Also consider Equip 135621 Cat6 shielded junction box, and Equip 221161 inline coupler for patch cords.
Not sure which coupler or jack you need? Send us the cable category and where it will be installed and we will check before you order.
Features - Equip - 135410
Colour
white
More Details
Product Code
04:375573
EAN Code
4015867225912
Manufacturer
Equip
