equip MTP to SC Trunk Fiber Patch Cord, OM4 Multi-Mode 50/125, 8 Fibres, MTP Female to 4 × Duplex SC, 3 m, Aqua
Brand:
Equip
equip MTP to SC Trunk Fiber Patch Cord, OM4 Multi-Mode 50/125, 8 Fibres, MTP Female to 4 × Duplex SC, 3 m, Aqua
€114.55 inc. VAT
25557307
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
equip 25557307 — MTP to SC Trunk Fiber Patch Cord, OM4, 8 Fibres, 3 m
MTP (female) ↔ SCOM4 · 50/125 µm8 fibres3 m · aqua LSZH
The equip 25557307 is a 3 m multi-mode OM4 trunk patch cord with an 8-fibre MTP connector (female) on one end and SC connectors on the other — four duplex SC pairs, as shown in the manufacturer's product image. It breaks a parallel-optic MTP link out to individual SC ports, for example from an MTP cassette or 40G SR4 port to SC-terminated patch panels or equipment.
The cable uses OM4 50/125 µm fibre in an aqua LSZH jacket, with heat-shrink tubing for strain relief at the connector transition and controlled fibre overcut on the MTP end for consistent mating. It is intended for high-density backbone and data-centre cabling where MTP trunks meet duplex SC infrastructure.
Before you order: The MTP end is female (unpinned), so it must mate with a male (pinned) MTP connector, typically inside a cassette or an MTP adapter with a pinned partner. equip does not publish the polarity method for this cord — check your system's polarity plan (Type A/B/C) before ordering, or send us the details. Multi-mode OM4 only.
What's in the Box
- 1 × equip MTP/SC trunk fiber patch cord, OM4, 3 m
What It Means in Practice
- Use it to land an 8-fibre MTP trunk on four duplex SC ports — e.g. legacy SC patch panels or SC-port equipment.
- OM4 supports the longest multi-mode reach for 10G/40G/100G short-reach optics.
- Female MTP to pinned MTP is the rule: two female or two male MTP connectors cannot mate.
- The aqua jacket identifies OM3/OM4 multi-mode at a glance in a crowded rack.
What Will Not Work
- It will not mate with another female MTP connector — the far side must be pinned (male).
- It will not work on single-mode systems.
- It does not have LC connectors — for LC equipment you need an MTP–LC version.
- Polarity is not stated by equip; a mismatched polarity plan will need a change elsewhere in the channel.
Key Features
MTP to SC breakout
8-fibre MTP (female) to SC — four duplex pairs.
OM4 fibre
50/125 µm multi-mode for high-speed short-reach links.
Strain relief
Heat-shrink tubing at the connector transition; controlled MTP fibre overcut.
LSZH jacket
Aqua low-smoke zero-halogen jacket; RoHS compliant.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
MTP-to-SC fan-outs are how parallel-optic trunks reach older SC infrastructure. Get two details right before ordering — MTP gender (this one is female) and the polarity method of your system — and keep the fibre type OM4 throughout. Mount the breakout neatly with suitable rack accessories.
✓ Buy it if you need to break out an 8-fibre OM4 MTP link to SC ports and your far side is a pinned MTP.
✕ Skip it if your equipment uses LC, your system is single-mode, or the mating MTP is also female.
→ Also consider equip 25555407 (MTP to MTP OM4 trunk, Type B, 7 m) for MTP-to-MTP runs.
Send us the transceiver or cassette model and your polarity plan and we will confirm the right MTP cord before you order.
Features - Equip - 25557307
Length
3m
More Details
Product Code
04:200315
EAN Code
4015867192689
Manufacturer
Equip
