Honeywell RS-232 Cable for Magellan Aux Port 3 m Straight for Xenon 1900 and Xenon XP Scanners, 5V Signals, Black

The Honeywell CBL-MAG-300-S00 is a black, straight 3 m RS-232 cable with a 10-pin modular plug that connects a Honeywell Xenon handheld scanner to the auxiliary scanner port of a Magellan bioptic (in-counter) scanner at the checkout.

"MAG" in the part number stands for Magellan Aux Port, not a magnetic stripe reader. Honeywell lists it in the Xenon accessory guide as an RS-232 cable with 5V signals and the option to take power from the host scanner. The bioptic forwards the handheld's barcodes to the POS over its own connection, so the handheld does not need a separate port on the terminal.

• 1 × Honeywell RS-232 cable, Magellan Aux Port, 10-pin modular, 3 m, straight, black (CBL-MAG-300-S00)

• The handheld Xenon becomes a second scanner at the lane for heavy, bulky or awkward items that cannot be passed over the bioptic window.
• Both scanners share the bioptic's single connection to the POS, so no extra terminal port or driver is needed.
• With host scanner power, the handheld is fed through the cable and does not need its own power supply at the lane.
• The straight 3 m cord reaches across a typical checkout and lies flat along the counter.
• The auxiliary port on the bioptic must be enabled, and the Xenon must be set to RS-232; both are done with configuration barcodes or the bioptic's own settings.

• Direct connection to a PC or POS serial (COM, DB9) port — use Honeywell CBL-020-300-C00 instead.
• Honeywell Stratos bioptic auxiliary ports — Honeywell lists CBL-420-300-C00 for those.
• USB, keyboard wedge or IBM 46xx hosts.
• Scanners from other brands, or Honeywell models with a fixed cord.
