Intel E10GSFPSR Ethernet SFP+ SR Optics Dual Rate 10GBASE-SR 1000BASE-SX 850 nm LC Multimode for X520 and X710
Brand:
Intel
Intel E10GSFPSR Ethernet SFP+ SR Optics Dual Rate 10GBASE-SR 1000BASE-SX 850 nm LC Multimode for X520 and X710
€46.12 inc. VAT
E10GSFPSR
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Intel E10GSFPSR — SFP+ SR Optic for Intel Adapters
10G / 1G dual rate850 nmLC duplexIntel NICs
The Intel Ethernet SFP+ SR Optics (E10GSFPSR) is Intel’s short-reach multimode optic for its 10GbE SFP+ network adapters. It runs at either 10GBASE-SR or 1000BASE-SX at 850 nm over an LC duplex connection, reaching 300 m at 10G on OM3 fibre, with digital diagnostics. It is the optic to order when an Intel X520 or X710 adapter in a server needs a fibre link to the switch. In practice, multimode optics are the cheaper choice for links inside one building: most server rooms and floor risers already carry OM3 or OM4 fibre, and the module plus a short patch cord is all a port needs. Before you order, check the fibre grade printed on the cable jacket and the real length of the run, including patch panels.
Compatibility — check before buying:
Intel states that X520 and X710 adapters work only with Intel-branded SFP+ optics — the reason to buy this part. It is made for Intel adapters, not for switches. It needs multimode fibre. The E10GSFPSRX is the extended-temperature version and runs at 10G only, so choose this E10GSFPSR if you need 1G; the E10GSFPLR is the single-mode version. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ Intel X520 and X710 server adapters
✓ 10G server-to-switch links on multimode
✓ 1G fibre links from the same adapter
✓ Replacing a failed Intel SR optic
✓ OM3 runs up to 300 m
✓ Servers that must keep Intel-only optics
Key Features
Made for Intel adapters
Intel-branded, so X520 and X710 adapters, which reject other brands of SFP+ optics, accept it.
10G or 1G
Dual rate: runs 10GBASE-SR or 1000BASE-SX, so the same optic can link to a 1G switch port today and a 10G one later.
Multimode fibre, short reach
Built for the short runs inside a building or data room over OM-grade multimode fibre. Reach depends on the fibre grade — check what is actually in your walls before you plan a link.
Monitoring you can read
Digital diagnostics (SFF-8472) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We sell the E10GSFPSR to customers with Intel X520 or X710 adapters, which will not accept other brands of SFP+ optics. Order the switch-side optic separately in the switch’s own coding, and check the fibre grade — old OM1 cable limits a 10G link to 33 m. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You have an Intel X520 or X710 adapter and need a 10G or 1G link over multimode fibre.
Skip it if
The optic is for a switch or a non-Intel card, your fibre is single-mode, or you need extended temperature at 10G only.
Also consider
Intel E10GSFPLR for single-mode fibre.
Features - Intel - E10GSFPSR
More Details
Product Code
04:115633
EAN Code
0735858211956
Manufacturer
Intel
