LevelOne 16-Port PS/2-USB VGA KVM switch | KVM-3216
The LevelOne KVM-3216 16-port combo KVM switch enables users to control and manage a server farm or computers connected to the KVM switch with either the local console or remote console port.Local ConsoleThe KVM-3216 Combo KVM Switch is easy to connect to a keyboard and mouse with a VGA monitor through the local console port. This enables a user to control systems connected to the KVM switch directly.Remote ConsoleIn order to make use of the remote control feature.
- 16-port Rackmount USB-PS/2 KVM switch with OSD
- Cascadable up to16 units using daisy-chain cable
- Daisy-chaining distance up to 30 M
- Port capacity scalable up to 256 PCs (16 x KVM-3216)
- USB and PS/2 interface support on both console and PC side
- Support Microsoft and Logitech standard 5-key mouse and compatibles
- Computer selection and operation using front-panel push buttons , keyboard hotkeys and OSD Menu
- Support for DOS, Windows 95/98/SE/ME/2000/XP/Vista/7, Linux, MacOS, etc.
- Numerical LED display and LED indicators for easy bank/port status monitoring
- Active Sync Replication for DDC emulation
- Keyboard/mouse emulation to ensure compatibility to all machines and operating systems
- Extensive support for USB keyboards and mice
- One controller per port to keep keyboard and mouse alive
- Enhanced PS/2 mouse reset hotkeys for non-PnP OS such as Win NT 4.0 and Linux
- Buzzer sound for hotkey and port switching confirmation
- Autoscan period programmable 10 ~ 95 through OSD Menu option
- Password protection
- Auto-logout timeout support
- High VGA resolution 2048 x 1536
- PC side emulation module upgradable
- Firmware upgrade
Product Specification
Keyboard port type | USB, PS/2 |
Mouse port type | USB, PS/2 |
Video port type | VGA |
Maximum resolution | 2048 x 1536 pixels |
Scan interval | 35,70,10,40,80,15,45,90,20,50,25,55,30,60 s |
Auto scan delay (min) | 10 s |
Product colour | Black |
Rack capacity | 1U |
Housing material | Metal |
Power source | DC |
DC input voltage | 9 V |
Input current | 1 A |
Windows operating systems supported | Windows 7 Professional x64, Windows Vista Enterprise x64, Windows 7 Starter, Windows Vista Home Basic, Windows 7 Starter x64, Windows Vista Home Basic x64, Windows 7 Ultimate, Windows 95, Windows Vista Home Premium, Windows 2000, Windows 7 Ultimate x64, Windows 98, Windows Vista Home Premium x64, Windows 7 x64, Windows 98SE, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows 7, Windows ME, Windows Vista x64, Windows 7 Enterprise, Windows XP, Windows 7 Enterprise x64, Windows XP Home, Windows 7 Home Basic, Windows XP Home x64, Windows 7 Home Basic x64, Windows Vista, Windows XP Professional, Windows 7 Home Premium, Windows Vista Business, Windows XP Professional x64, Windows 7 Home Premium x64, Windows Vista Business x64, Windows 7 Professional, Windows Vista Enterprise |
