LevelOne POI-5003 Gigabit PoE Injector 90W IEEE 802.3af/at/bt Single Port Wall Mount Power Supply Included Black

Brand:
LevelOne
LevelOne POI-5003 Gigabit PoE Injector 90W 802.3bt
LevelOne POI-5003 Gigabit PoE Injector 90W IEEE 802.3af/at/bt Single Port Wall Mount Power Supply Included Black
€155.93 inc. VAT
Buy
POI-5003
€131.03
€155.93 inc. VAT
Ships from EU stock: 37 item(s)
+ −
Add to wish list Ask a question
Product Code
04:430060
EAN Code
4015867231135
Manufacturer
LevelOne

Quick Specs

PoE
802.3af/at/bt, 90 W
Data
10/100/1000 Mbps
Reach
Up to 100 m
Surge
6 kV (IEC 61000-4-5)
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

POI-5003 Gigabit PoE Injector — 90 W

90 W802.3btGigabitWall mount

The LevelOne POI-5003 is a single-port Gigabit PoE injector with a 90 W IEEE 802.3bt power budget. It adds power to an existing Ethernet link, so one cable carries 10/100/1000 Mbps data and up to 90 W to a device up to 100 m away. LevelOne names high-power PTZ cameras and LED lighting among the loads it is built for. It powers all four pairs (Mode A/B), detects and protects non-standard devices, has 6 kV surge protection and a wall-mount design, and the power supply is built in. It measures 179.5 × 65.3 × 40 mm and weighs 0.75 kg.

Compatibility — check before buying:
For IEEE 802.3af/at/bt devices. It is not a passive-PoE injector. LevelOne includes a power cord but does not state its plug type, so tell us if you need a UK plug for Cyprus. The device receives the full 90 W only if it supports 802.3bt Type 4; for 30 W or 60 W devices a smaller injector is enough. LevelOne also sells the POI-5002W90, a different 90 W model. Not sure? Tell us your model and we check it for you.

Best For

✓ High-power PTZ cameras
✓ 802.3bt access points
✓ LED lighting over PoE
✓ Digital signage
✓ Single remote devices
✓ Switches without 802.3bt

Key Features


90 W PoE
IEEE 802.3af/at/bt on four pairs.

Gigabit data
10/100/1000 Mbps wire speed.

Device protection
Auto-detection and protection of non-standard devices.

Surge protected
6 kV, IEC 61000-4-5.

Technical Specifications

Identification
Brand LevelOne
Product POI-5003 Gigabit PoE Injector, 90W, 802.3af/at/bt
Part Number POI-5003
EAN / GTIN 4015867231135
Product Type Gigabit PoE injector, single port
PoE & Data
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3af, 802.3at, 802.3bt
Power budget 90 W
PoE mode Mode A/B
Pin assignment 1/2 (+), 3/6 (−) and 4/5 (+), 7/8 (−)
Data rate 10/100/1000 Mbps
Reach Up to 100 m
Ports Single injector port
Power & Indicators
Power supply Included (built in)
Indicators Power, Link/Act
Surge protection 6 kV, 10/700 µs (IEC 61000-4-5)
Physical & Environment
Dimensions 179.5 × 65.3 × 40 mm
Weight 0.75 kg
Colour Black
Operating temperature 0 to 40 °C
Storage temperature 0 to 70 °C
Humidity 0–95% RH
Certifications CE, FCC
Before You Order
Your device 802.3af/at/bt, not passive PoE
Power need Up to 90 W
Mains plug Ask us about the included cord
In the Box
Included POI-5003 injector, power cord
Not Included Ethernet cables; mounting screws
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term LevelOne does not publish a warranty term for this item on its product page or datasheet. Singular’s direct warranty is 1 year, and we support you locally for anything beyond it.

Frequently Asked Questions

How much power does it deliver?
Up to 90 W, IEEE 802.3bt.
Is it Gigabit?
Yes, 10/100/1000 Mbps.
Does it work with passive PoE devices?
No. It follows IEEE 802.3af/at/bt.
Is the power cord included?
Yes; ask us about the plug type.
Singular Expert Insight
90 W injectors are the practical answer for one heavy PTZ with heaters and IR on a switch that tops out at 30 W. For many high-power devices, an 802.3bt switch is simpler. See our PoE switches and IP cameras.

Buyer’s Guide

Buy it if

You need up to 90 W 802.3bt PoE for one device.

Skip it if

Your device uses passive PoE.

Also consider

An 802.3bt PoE switch for several high-power devices.
