LevelOne SFP-2605 — Industrial 2.5G SFP, 1550 nm, 40 km
2.5 Gbps1550 nmUp to 40 km−40 to 85 °C
The LevelOne SFP-2605 is an industrial 2.5 Gbps SFP transceiver for single-mode fibre, reaching up to 40 km at 1550 nm over a duplex LC connection, with digital diagnostics. It is rated from −40 to 85 °C, so it suits industrial switches in outdoor cabinets, substations and plant rooms, and LevelOne notes its 1550 nm wavelength can share fibre with CWDM/DWDM systems. In practice, single-mode optics are the choice when a link leaves the building or runs several hundred metres: the OS2 fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.
Compatibility — check before buying:
It is a 2.5 Gbps optic: both ends must run 2.5G, so it will not link to a 1G (1000BASE) module, and the switch port must support 2.5G SFP optics — many SFP ports run 1G only and many SFP+ ports run 1G or 10G only. It needs single-mode fibre. Its transmitter is stronger than the commercial SFP-2505 (0 to +5 dBm), so LevelOne’s two 1550 nm modules are not interchangeable spares for each other — plan the same model at both ends. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ Industrial switches in outdoor cabinets
✓ Substations and utility networks
✓ 2.5G links up to 40 km
✓ Fibre shared with WDM systems
✓ Smart-grid and traffic systems
✓ Unheated plant rooms
Key Features
Rated −40 to 85 °C
Industrial temperature rating for switches in outdoor cabinets, substations and plant rooms.
Single-mode fibre, long reach
Built for single-mode (OS1/OS2) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.
Monitoring you can read
Digital diagnostics (DDM) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
The SFP-2605 is the module we recommend for 2.5G fibre links in industrial and outdoor enclosures. Confirm that the industrial switch accepts 2.5G SFP optics, and order both ends together. For indoor rooms the commercial SFP-2505 does the same job. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You need a 2.5G single-mode link up to 40 km on industrial switches in hot or cold locations.
Skip it if
Your ports run only 1G or 10G, or the equipment sits in an air-conditioned room (the SFP-2505 is enough).
Also consider
LevelOne SFP-2505 (commercial) or SFP-2604 (1310 nm industrial).
