PLANET MGB-Series MGB-TSX - SFP (mini-GBIC) transceiver module - GigE - 1000Base-SX - LC multi-mode - up to 550 m - 850 nm | MGB-TSX
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-SX |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 550 m |
| Compliant Standards | IEEE 802.3z |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-SX - LC multi-mode x 2 |
| Miscellaneous | |
| Compliant Standards | Plug and Play, EN 60825-1 |
| Environmental Parameters | |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
Features - Planet - MGB-TSX
More Details
Product Code
04:199680
EAN Code
4711213687730
Manufacturer
Planet
