PLANET MGB-TSA — Industrial Gigabit BiDi SFP, Tx 1310 nm
1 GbpsOne fibre strandTx 1310 nm−40 to 85 °C
The PLANET MGB-TSA is an industrial Gigabit 1000BASE-BX (WDM) mini-GBIC module that runs a full link over one multimode fibre strand, up to 2 km. It transmits at 1310 nm and receives at 1550 nm through a simplex LC/UPC connector, with digital diagnostics, and is rated −40 to 85 °C for cabinets, factories and transport sites. It pairs with the PLANET MGB-TSB at the other end. In practice, bidirectional optics are used where fibre is scarce — a leased dark-fibre strand, a full duct or an old building link. Before you order, confirm which end of the strand gets which module type and that the fibre is single-mode all the way.
Compatibility — check before buying:
This is one half of a pair: the other end needs a MGB-TSB, which is not included; two MGB-TSA modules will not link. PLANET publishes it for multimode fibre up to 2 km — it is not the 20 km single-mode BiDi pair, which PLANET sells as MGB-LA20 / MGB-LB20. The connector is simplex LC for one strand. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ Industrial switches in cabinets
✓ Gigabit over one multimode strand
✓ Factory and plant-room links up to 2 km
✓ Transport and roadside installations
✓ Doubling the use of an existing fibre pair
✓ Replacing a failed BiDi module
Key Features
Built for harsh sites
Rated −40 to 85 °C, so it keeps working in street cabinets, plant rooms and on factory floors.
One strand instead of two
A bidirectional module sends and receives on different wavelengths over a single fibre strand, which halves the fibre you need. The price of that is pairing: the two ends must be opposite types.
Monitoring you can read
Digital diagnostics (DDM) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We suggest the MGB-TSA / MGB-TSB pair for industrial Gigabit links over one multimode strand inside a site. Order both ends together and label them. For single-mode routes between sites, the MGB-LA20 / MGB-LB20 pair is the right choice. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You need industrial Gigabit over one multimode strand up to 2 km and order the MGB-TSB for the far end.
Skip it if
Your fibre is single-mode (MGB-LA20/LB20), the run is over 2 km, or you only order one end.
Also consider
PLANET MGB-TSB, the matching far-end module.
