Socket Mobile SocketScan S740 Bluetooth 1D/2D Barcode Scanner with OCR/MRZ Support, Black

Brand:
SOCKET MOBILE
Socket Mobile SocketScan S740 Black Bluetooth 1D 2D Barcode Scanner
Socket Mobile SocketScan S740 Bluetooth 1D/2D Barcode Scanner with OCR/MRZ Support, Black
€502.39 inc. VAT
Buy
CX3809-2569
€422.18
€502.39 inc. VAT
Ships from EU stock: 4 item(s)
+ −
Add to wish list Ask a question
Product Code
Y340805
EAN Code
0758497118882
Manufacturer
SOCKET MOBILE
Features
Bluetooth, Wireless

Quick Specs

Capture
1D/2D, paper and screens
Wireless
Bluetooth 2.1 + EDR · up to 10 m
Package
Scanner, batteries, charging cable, strap
Configuration
Black scanner; dock separate
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Wireless 1D/2D scanning for a tablet or desktop workflow

1D / 2DBluetoothPaper + screensBlack

The black Socket Mobile SocketScan S740 CX3809-2569 is a handheld Bluetooth barcode reader for retail counters, stock checks and service work. It reads supported 1D and 2D codes, including QR, on paper and screens, and sends the result to a paired host. This package includes one scanner, rechargeable NiMH batteries, a charging cable and a wrist strap. A compatible computer, tablet or phone and receiving application are required; a charging dock or stand is separate. OCR/MRZ reading needs appropriate configuration and software; the scanner alone does not authenticate an identity document or calculate age.

Before you order:
Check the exact host, Bluetooth profile, keyboard layout and application. HID sends keyboard-style input; application modes need suitable software integration. The supplied cable charges the scanner and does not turn it into a USB data scanner.

What's in the Box

  • 1 × black S740 CX3809-2569 scanner with 2 rechargeable 2000 mAh AA NiMH batteries.
  • 1 × charging cable, 1 × wrist strap and getting-started insert.
  • Charging dock, stand and receiving host are separate.

What It Means in Practice

  • Pair the scanner with the host using the mode supported by the application, open the receiving field and scan. Your POS or inventory software interprets the data and performs the transaction.
  • For example, scan a product’s printed barcode, then a supported QR code displayed on a customer’s phone. The software must understand both workflows.
  • Keep the charging cable available between shifts. Automatic presentation scanning requires the relevant mode and an appropriate separately selected dock or stand.

What Will Not Work

  • This is not a standalone inventory terminal or payment reader; the host application supplies the business functions.
  • OCR and barcode capture do not validate document authenticity or enforce age rules. Those functions depend on the receiving software and its supported document formats.

Key Features


Paper and screen codes
A 1D/2D imager handles supported printed labels and electronic barcodes.

Bluetooth host connection
Class 2 Bluetooth 2.1 + EDR supports HID and application profiles with compatible hosts.

Clear user feedback
LEDs, sound and vibration help the operator confirm scanning and connection status.

Barcode and OCR workflows
The S740 family supports OCR/MRZ capture for compatible applications; document processing remains a host-software function.

Technical Specifications

EXACT CONFIGURATION
MPN CX3809-2569
EAN 0758497118882
Colour Black
Configuration Scanner with charging cable; dock/stand separate
SCANNING
Engine Omnidirectional 1D/2D imager
Media Paper and electronic screens
Scan angle 44.5° horizontal × 33.5° vertical
Aimer LED pointer
Default 1D formats Bookland EAN, Codabar, Code 128, Code 39, Code 93, EAN/JAN-13, EAN/JAN-8, GS1-128, GS1 DataBar Expanded, Limited, Omnidirectional, Interleaved 2 of 5, ISBT 128 UDI, Trioptic, UPC-A, UPC-E
Default 2D formats Aztec, Composite, Data Matrix, GS1 Data Matrix, GS1 QR, Han Xin, MaxiCode, MicroPDF417, Micro QR, PDF417, QR
Additional formats Code 11, Matrix 2 of 5, MSI; Australian Post, Japan Postal, Mailmark, Netherlands KIX, UK Postal, US Planet, US Postnet, USPS 4CB
OCR support MRZ; OCR-A, OCR-B, OCR USC, passport, MICR E13B; software/configuration dependent
TYPICAL DECODE DISTANCES
Code 39, 5 mil 5.5–11.5 cm
Data Matrix, 10 mil 4–10 cm
UPC/EAN, 13 mil 5.5–28 cm
Code 128, 15 mil 5.5–38 cm
QR, 15 mil 4–20 cm
Distance conditions Depends on barcode size, symbology and label medium
Format configuration Some supported formats require enabling; verify your labels
WIRELESS AND HOST
Bluetooth Class 2, version 2.1 + EDR
Encryption 56-bit
Range Up to 10 m, host/environment dependent
Profiles HID, SPP, MFi-SPP; host-dependent availability
Host platforms Apple iOS, Android, Windows; Mac OS in HID mode; verify app/profile
Setup / integration Socket Mobile Companion; CaptureSDK-integrated applications
BATTERY AND PHYSICAL
Batteries 2 × rechargeable AA (LR6) NiMH, 2000 mAh, replaceable
Charge time Approximately 6 hours
Standby reference Over 20 hours
Battery conditions Runtime depends on scanning duty cycle, light, temperature and battery age
Dimensions, manufacturer diagram 5.2 × 1.4 × 1.6 in
Trigger life 1 million actuations
Controls Scan button and power button; on-screen keyboard control in HID
Feedback Battery, Bluetooth and scan LEDs; beep and vibration
ENVIRONMENT AND SUPPORT
Ambient light 0–100000 lux
Operating temperature 0°C to 45°C
Storage temperature −40°C to 70°C
Humidity 95% at 60°C, non-condensing
Drop reference 4 ft onto linoleum
Manufacturer warranty 1 year included, subject to Socket Mobile terms
LED safety IEC/EN 62471, Exempt Group

Frequently Asked Questions

Is a charging dock included?
No. CX3809-2569 includes the charging cable, rechargeable batteries and wrist strap. Select a dock or stand separately.
Does the charging cable transfer scanned data?
The cable is for charging. Scanned data is sent through the configured Bluetooth connection to the receiving host.
Can it read QR from a phone?
Yes, supported QR codes on screens can be read. Your receiving application must support the intended use.
Singular Expert Insight
Choose this cable-charged black configuration when you need handheld Bluetooth scanning and already have the receiving software. Check a real label sample and the host profile before deployment. Compare other readers: Barcode scanners at Singular

Buyer’s Guide

✓

Buy it if

 you need handheld 1D/2D Bluetooth scanning with cable charging.
✕

Skip it if

 you need a rugged industrial scanner, included charging stand or standalone software.
→

Also consider

 a verified dock or stand bundle for a permanent counter position.
Confirm label samples, application support and charging accessories with Singular.
