StarTech.com SMLCSC-OS2-8M Fiber Optic Cable LC to SC UPC OS2 Single Mode Duplex 8 m 9/125 LSZH Bend Insensitive Yellow

Brand:
StarTech.com
StarTech LC to SC OS2 Single-Mode Duplex Fiber 8 m
StarTech.com SMLCSC-OS2-8M Fiber Optic Cable LC to SC UPC OS2 Single Mode Duplex 8 m 9/125 LSZH Bend Insensitive Yellow
€28.29 inc. VAT
Buy
SMLCSC-OS2-8M
€23.77
€28.29 inc. VAT
Ships from EU stock: 5 item(s)
+ −
Add to wish list Ask a question
Product Code
CS63290
EAN Code
0065030928434
Manufacturer
StarTech.com

Quick Specs

Connectors
LC/UPC → SC/UPC duplex
Fibre
OS2 single-mode 9/125 µm
Length
8 m
Jacket
LSZH · bend insensitive
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

StarTech.com SMLCSC-OS2-8M — LC to SC OS2 Single-Mode Duplex Fibre, 8 m

LC → SCOS2 single-mode8 mLSZH

The StarTech.com SMLCSC-OS2-8M is an 8 m single-mode duplex fibre patch cable with LC connectors on one end and SC connectors on the other, both UPC polished. It uses OS2 9/125 µm bend-insensitive fibre with a 0.3 dB insertion loss, in a yellow LSZH jacket. In practice it links an SFP port with LC optics to an older switch, media converter or patch panel with SC ports, for 1G, 10G and higher single-mode links.

Compatibility — check before buying:
Mixed connectors: LC on one end, SC on the other — it is wrong for LC-to-LC links. Both ends are UPC; it must not be used on APC (green, angled) ports. It is single-mode: it needs single-mode optics such as LR or ER at both ends, not multimode SR. Tell us both ports and we confirm.

Best For

✓ SFP switch to SC patch panel
✓ Media converters with SC ports
✓ Building-to-building links
✓ Data centre and comms rooms
✓ Single-mode LR and ER optics
✓ Upgrading older SC equipment

Key Features


LC to SC
Connects LC-based SFP optics to SC ports without an adapter.

OS2 single-mode
9/125 µm fibre for long-reach links; backward compatible with OS1.

Bend insensitive
10 mm bend radius for tight routing in racks and trays.

Low loss, tested
0.3 dB insertion loss and 55 dB return loss, supplied with a test report.

Technical Specifications

Identification
Brand StarTech.com
Part Number SMLCSC-OS2-8M
EAN / GTIN 0065030928434
Colour Yellow
Connectors
End 1 LC duplex, UPC
End 2 SC duplex, UPC
Fibre
Type OS2 single-mode, 9/125 µm
Wavelength 1260–1625 nm
Bend Radius 10 mm (bend insensitive)
Backward Compatible OS1
Performance
Insertion Loss 0.3 dB
Return Loss 55 dB
Cable
Length 8 m
Jacket LSZH
Diameter 2 mm
Before You Order
Check Both Ends Confirm one port is LC (the small square connector used by SFP optics) and the other is SC (the larger square push-pull connector).
Check the Polish Both ends are UPC. Ports marked APC or with green connectors need APC cable.
Check the Optics Use single-mode optics (LR, ER, BiDi SM) at both ends; multimode SR optics need OM3/OM4 cable.
Ask Us Send us the model, a photo or the part you use today and we confirm the match before we dispatch. Singular supports you locally in Cyprus.
Handling Notes
Cleaning Keep dust caps on until connection and clean the ferrules before plugging in; dirty connectors are the most common cause of link loss.
Bending Bend insensitive to 10 mm, but avoid sharp kinks and do not step on or crush the cable.
Polarity If the link does not come up, swap the two fibres at one end (Tx to Rx).
In the Box
Included 1 × fibre cable, 1 × test report
Not Included Couplers, adapters, transceivers
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term StarTech.com publishes a lifetime warranty on this cable in its datasheet. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process for its full duration.

Frequently Asked Questions

Can I use it for LC to LC?
No. One end is LC and the other SC. For LC to LC links choose an LC-LC single-mode cable.
Does it work with multimode SFPs?
No. It is OS2 single-mode fibre. Use it with single-mode optics such as 10GBASE-LR or ER; for SR optics you need OM3/OM4 multimode cable.
Is it APC or UPC?
UPC on both ends. Do not connect it to APC (green, angled) ports.
Is it suitable for indoor runs?
Yes. The LSZH jacket produces little smoke in a fire, which suits offices, racks and public buildings.
Singular Expert Insight
We suggest the SMLCSC-OS2-8M when newer LC-based switches meet SC patch panels or converters: it removes an adapter and a loss point. Check both ends are UPC and single-mode. See our fibre optic cables and SFP transceivers.

Buyer’s Guide

Buy it if

You need 8 m of single-mode fibre between an LC port and an SC port.

Skip it if

Both ends are LC, or your optics are multimode or APC.

Also consider

StarTech.com SFP-10G-ER-ST 10GBASE-ER single-mode SFP+.
