StarTech.com MASFP10GBLR — Meraki-Compatible 10G LR SFP+
10 Gbps10GBASE-LRMeraki codedUp to 10 km
The StarTech.com MASFP10GBLR is a 10 Gbit SFP+ transceiver for single-mode fibre, reaching up to 10 km at 1310 nm over an LC duplex connection. It is programmed as a Cisco Meraki MA-SFP-10GB-LR, so Meraki MS switches and MX security appliances accept it, and it supports digital diagnostics. In practice, single-mode optics are the choice when a link leaves the building or runs several hundred metres: the OS2 fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.
Compatibility — check before buying:
It is coded for Cisco Meraki (MA-SFP-10GB-LR), for Meraki MS switches and MX appliances. For Cisco Catalyst or Nexus switches choose the Cisco-coded SFP10GLRST — same optics, different coding. It needs single-mode fibre and a 10G SFP+ port. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ Meraki MS switch uplinks
✓ Meraki MX appliance fibre ports
✓ Links between buildings up to 10 km
✓ Cloud-managed campus networks
✓ Spare Meraki optics at a lower cost
✓ Single-mode backbones
Key Features
Coded for Meraki
Programmed as a Meraki MA-SFP-10GB-LR, so Meraki MS switches and MX appliances accept it.
Single-mode fibre, long reach
Built for single-mode (OS1/OS2) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.
Monitoring you can read
Digital diagnostics (DDM) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
For Meraki networks we recommend matching the optic coding to the Meraki part, which is what the MASFP10GBLR does. If the same site also has Catalyst switches, order the SFP10GLRST for those ports — the optics link to each other, only the coding differs. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You need 10G single-mode up to 10 km on Meraki MS switches or MX appliances.
Skip it if
Your switches are Catalyst or Nexus, or your fibre is multimode.
Also consider
StarTech.com SFP10GLRST for Cisco Catalyst and Nexus.
