StarTech.com LOOPBACKLCLC00DB LC/UPC Single Mode Fiber Loopback Module 0 dB OS1/OS2

Brand:
StarTech.com
StarTech LOOPBACKLCLC00DB LC/UPC Single Mode Loopback 0dB
StarTech.com LOOPBACKLCLC00DB LC/UPC Single Mode Fiber Loopback Module 0 dB OS1/OS2
€64.45 inc. VAT
Buy
LOOPBACKLCLC00DB
€54.16
€64.45 inc. VAT
Ships from EU stock: 5 item(s)
+ −
Add to wish list Ask a question
Product Code
CR72310
EAN Code
0065030923538
Manufacturer
StarTech.com
Quick Specs
Type
Fiber loopback test module
Connectors
Duplex LC/UPC
Key spec
0 dB · repeatability 0.2 dB · 1,000 cycles
Compatibility
Single mode OS1/OS2 9/125 µm
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

StarTech.com LOOPBACKLCLC00DB — LC/UPC Single Mode Fiber Loopback, 0 dB

LC/UPC single mode0 dB loopback1,000 test cycles

The StarTech.com LOOPBACKLCLC00DB is an LC/UPC duplex fiber loopback module for single-mode OS1/OS2 (9/125 µm) networks that routes the transmit signal straight back to the receive side of the same port. Technicians use it to verify transceivers, switch ports and patch panels during installation and fault isolation; the low-loss 0 dB design gives a clean baseline, with repeatability within 0.2 dB and return loss above 50 dB.

Compatibility note: Single-mode LC/UPC only — it will not suit multimode (OM3/OM4) or APC-polished ports. Long-reach, high-power optics can overload their own receiver on a 0 dB loop, so check the transceiver receive range and add an attenuator if needed.

Technical Specifications

Identification
Part Number LOOPBACKLCLC00DB
EAN / GTIN 0065030923538 (UPC 065030923538)
MPN LOOPBACKLCLC00DB
Brand StarTech.com
Colour Blue
Specifications
Type Duplex LC fiber loopback module
Fiber Single mode OS1 / OS2 · 9/125 µm
Connector and polish LC/UPC · ceramic ferrules · IEC 61754-20
Loss 0 dB (low-loss) · repeatability within 0.2 dB · return loss above 50 dB
Durability Rated for 1,000 test cycles · dust caps included
Size, weight and temperature 50.5 × 14.2 × 8.5 mm · 4 g · -40 °C to 75 °C
Package and Warranty
In the box and warranty 1 × LC fiber loopback module · 2-year StarTech.com warranty

Frequently Asked Questions

What does a fiber loopback module test?
It lets a switch, media converter or transceiver receive its own transmitted light, so you can confirm the optic, port and link-up behaviour without a far-end device — useful for commissioning and for isolating whether a fault is in the equipment or the cabling.
Can I use it with multimode SFP+ transceivers?
No. It is built for single-mode 9/125 µm fibre with LC/UPC connectors. Multimode transceivers such as 10GBASE-SR need a multimode loopback module.

Singular Expert Insight

A single-mode LC loopback belongs in every network technician kit: it turns a “no link” call into a quick test of the optic and port before anyone pulls cables. The 0 dB version gives the truest baseline for short and medium reach optics; for long-haul modules use an attenuated loopback. It pairs well with SFP+ media converters such as the MCM10G6SSFP.
✓ Buy it if you commission or troubleshoot single-mode LC transceivers, switch ports or patch panels.
✕ Skip it if your links are multimode or use APC-polished connectors.
→ Also consider FOCPENMPO316C (MPO-16 cleaning pen) · MCM10G6SSFP (10G media converter).
