Motorola LS1203-1UB50 Symbol LS1203 - Barcode scanner - 100 scan / sec - decoded - USB (pack of 50 )
Symbol LS1203 - Barcode scanner - 100 scan / sec - decoded - USB (pack of 50 )
Motorola LS1203. Scanning: Laser, 100 sec/page, 650nm, UPC/EAN UPC/EAN + Supplementals UCC/EAN 128 Code 39 Code 39 Full ASCII Code 39 TriOptic, -60 - 60 °, -65 - 65 °, -30 - 30 °. Connectivity: USB. Energy management: 5 V, 100 mA. Weight & dimensions: 60 x 180 x 62 mm, 122 g. Colour: White. Environmental conditions: 5 - 95 %, -40 - 70 °C, 0 - 50 °C
This bi-directional LS1203 handheld scanner handles all 1D bar codes and is ideal for small retailers. It delivers the functionality, features and reliability needed to improve operational efficiencies from the check-out line to the storeroom. It minimizes manual keying — ensuring accuracy in all customer transactions — and it automates paper-based inventory processes. The device easily integrates ...
This bi-directional LS1203 handheld scanner handles all 1D bar codes and is ideal for small retailers. It delivers the functionality, features and reliability needed to improve operational efficiencies from the check-out line to the storeroom. It minimizes manual keying — ensuring accuracy in all customer transactions — and it automates paper-based inventory processes. The device easily integrates multiple interfaces to help ensure connectivity to a host and PC system.
Durable, single-board construction
Meets 5-ft drop tests, significantly reducing downtime and repair costs.
Multiple interfaces: RS232, USB, keyboard wedge (KBW) in one scanner
Simplifies installation and integration, ensuring future compatibility.
Sleek, lightweight, ergonomic design
Maximizes comfort for all-day use.
Intuitive scanning and plug-and-play capability
Minimizes setup and training time.
Choice of triggered or continuous mode
Ensures versatile, accurate first-time scanning.
|
Scan type
|
Laser
|
|
Scan speed
|
100 sec/page
|
| Light source |
650nm |
| Decoding standards |
UPC/EAN
UPC/EAN + Supplementals
UCC/EAN 128
Code 39
Code 39 Full
ASCII
Code 39 TriOptic
Code 128
Code 128 Full ASCII
Codabar
Interleaved 2/5
Discrete 2/5
Code 93
MSI
Code 11
IATA
GS1 DataBar (RSS)
Chinese 2/5 |
| Yaw reading angle |
-60 - 60 ° |
| Pitch reading angle |
-65 - 65 ° |
| Tilt reading angle |
-30 - 30 ° |
|
Interface
|
USB
|
| Input voltage |
5 V |
| Current consumption |
100 mA |
|
|
Safety
|
UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, EN 60825-1, IEC 60825-1, 21CFR1040.10
|
| Electromagnetic emissions |
FCC P. 15 Cl. B, ICES 003 Cl. B |
| Colour of product |
White |
|
Dimensions W x D x H
|
60 x 180 x 62 mm
|
|
Weight
|
122 g
|
| Operating relative humidity range |
5 - 95 % |
| Storage temperature range (T-T) |
-40 - 70 °C |
| Operating temperature range (T-T) |
0 - 50 °C |
|
Symbol LS1203 - Barcode scanner - 100 scan / sec - decoded - USB (pack of 50 )
