TRENDnet TPE LG50 / Switch / unmanaged / 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 / desktop / PoE+ (32 W) | TPE-LG50
Please sign in so that we can notify you about a reply
Special Features
- LED indicators
- Metal housing
- Port isolation
Product Specification
| Device Type | Switch - 5 ports - unmanaged |
| Enclosure Type | Desktop |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 32 W |
| Performance | Switching capacity: 10 Gbps ¦ Forwarding performance (64-byte packet size): 7.44 Mpps |
| MAC Address Table Size | 2K entries |
| Jumbo Frame Support | 9KB |
| Features | VLAN support, half duplex mode, full duplex mode, wall mountable, Quality of Service (QoS), fanless, built-in DIP switch, port isolation, Class of Service (CoS), metal housing, long range PoE+ up to 200m at 10Mbps |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3p, IEEE 802.3at |
| RAM | 128 KB |
| Status Indicators | Power, alert, PoE, link/activity, link/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x Gigabit LAN RJ-45 PoE+ ¦ 1 x Gigabit LAN RJ-45 |
| Power | Power |
| Power Device | External power adapter |
| Power Provided | 54 V - 0.7 A |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 36.3 Watt |
| Miscellaneous | Miscellaneous |
| Compliant Standards | Plug and Play, FCC, RoHS, WEEE |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12.1 cm |
| Depth | 7.5 cm |
| Height | 2.6 cm |
| Weight | 246 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
Features - Trendnet - TPE-LG50
General
5-Port
More Details
Product Code
04:282652
EAN Code
0710931161304
Manufacturer
Trendnet
