Ubiquiti UniFi WAN Switch 1U Rack Managed Switch 3x 10G SFP+ 1x 1G RJ45 Redundant Gateway USW-WAN
Brand:
Ubiquiti
Ubiquiti UniFi WAN Switch 1U Rack Managed Switch 3x 10G SFP+ 1x 1G RJ45 Redundant Gateway USW-WAN
€373.23 inc. VAT
USW-WAN
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
UniFi WAN Switch
3x 10G SFP+1U RackmountShadow Mode HA
The Ubiquiti UniFi WAN Switch (USW-WAN) is the fiber counterpart to the USW-WAN-RJ45, purpose-built to interconnect resilient UniFi Cloud Gateway deployments. It provides three 10G SFP+ ports — typically one to a primary gateway, one to a redundant gateway running Shadow mode HA, and one for the incoming ISP fiber — plus a dedicated 1GbE RJ45 port for out-of-band management. A compact 1U enclosure, 20Gbps switching capacity and low 13W power draw suit always-on WAN edge deployments. Typically in stock with fast delivery across Cyprus.
Compatibility note: like the RJ45 variant, this switch does not provide gateway redundancy on its own — it is the fiber interconnect for two compatible UniFi Cloud Gateways running Shadow mode HA. SFP+ transceivers are sold separately.
Best For
✓ Fiber-based redundant UniFi gateway deployments
✓ Sites with SFP+ fiber WAN infrastructure
✓ Zero-downtime WAN failover requirements
✓ Mission-critical office or datacenter edges
✓ Compact 1U fiber WAN aggregation
✓ Out-of-band management via dedicated GbE port
Key Features
3x 10G SFP+ Ports
Fiber-based 10G ports connect primary/redundant gateways and the ISP fiber uplink.
Dedicated Management Port
A separate 1GbE RJ45 port keeps management traffic isolated from the WAN data path.
Compact, Low-Power 1U Design
20Gbps switching capacity in a small 1U chassis drawing just 13W, easing rack space and power planning.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Confirm your ISP handoff and gateway SFP+ ports before ordering — if your infrastructure is copper-based, the USW-WAN-RJ45 variant avoids extra media converters.
Buyer's Guide
Buy it if: you have fiber SFP+ infrastructure and need a redundant UniFi gateway interconnect.
Skip it if: your infrastructure is copper-based — choose USW-WAN-RJ45 instead.
Also consider: USW-WAN-RJ45 for copper WAN environments.
Features - Ubiquiti - USW-WAN
Colour
white
Interface
- Ethernet
Port Speed
- 1 Gbps,
- 10 Gbps
More Details
Product Code
04:537828
EAN Code
0810177160113
Manufacturer
Ubiquiti
