Wantec 5720 2wIP E-Series Two-Wire Ethernet/PoE Switch-Side Adapter, Screw Terminals, 10/100Mbps, 65W PSU

Brand:
Wantec
Wantec 5720 Black 2wIP E-Series Switch-Side Two-Wire Adapter
Wantec 5720 2wIP E-Series Two-Wire Ethernet/PoE Switch-Side Adapter, Screw Terminals, 10/100Mbps, 65W PSU
€259.73 inc. VAT
Buy
5720
€218.26
€259.73 inc. VAT
Ships from EU stock: 2 item(s)
+ −
Add to wish list Ask a question
Product Code
04:402694
EAN Code
4250367757208
Manufacturer
Wantec

Quick Specs

Role
Switch-side adapter
Ethernet port
1 × RJ45, 10/100Mbps
Cable link
2-pin screw terminal
Included PSU
56V DC / 65W
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Wantec 5720 — Ethernet and PoE over Two Wires

Switch-side unit10/100MbpsScrew terminals65W PSU included

Reuse a suitable two-wire route for network data and power instead of treating this as an ordinary RJ45 repeater. The 5720 connects to the network switch and supplies the link from its included power adapter; a compatible receiver is needed at the device end.

Compatibility — check before buying:
At least one switch-side and one receiver adapter are required. The 5722 is the screw-terminal device-side partner shown in the exact guide and is separately required. Respect terminal polarity and check cable quality, wire size, length and endpoint PoE demand together.

Key Features


Two-wire installation
The two-pin terminal carries the link between adapters; the RJ45 connects this unit to the switch.

Power budget depends on the route
The manufacturer’s 600m reference is accompanied by much lower delivered power on long cable runs. Use the qualified reference points below for planning.

Join control
The guide provides pairing, link removal and reset timing. The receiver’s PoE on/off switch is a 5722 feature, rather than a control on this unit.

Technical Specifications

Identification and interfaces
Brand / model / MPN Wantec 2wIP E-Series / 5720
EAN 4250367757208
Role Switch-side unit; RX designation in Wantec guide
Ethernet 1 × RJ45, 10/100Base-T, half/full duplex, auto-negotiation
Two-wire connector 2-pin screw terminal; observe polarity
Power input DC jack; included 56V DC / 65W adapter
PoE standards IEEE 802.3af / 802.3at
Exact-page power output limit Maximum 25.4W; delivered power depends on cable and distance
Link capability
Two-wire reach Up to 600m, subject to cable and power requirements
Series link bandwidth reference E-Series line transport up to 200Mbit/s; this unit’s RJ45 is 10/100Mbps
Multi-device reference Manufacturer states one 1-port sender can serve up to 4 receivers; shared route/power budget must be checked
Encryption / topology 128-bit AES; star, ring, daisy-chain or mixed, as manufacturer specifies
Basic setup Plug and play; no programming for basic configuration
Join button timing 1–3s on both adapters to link; 5–8s on remote to disconnect; 10–15s to reset
Indicators PWR power indication; LINK connection indication; RJ45 data/connection indication
Manufacturer power/distance references
26AWG / 0.4mm cable 100m: 18W; 200m: 8.06W; 400m/600m not supported in guide chart
24AWG / 0.5mm cable 100m: 23.8W; 200m: 12.1W; 400m: 6.1W; 600m not supported in guide chart
22AWG / 0.6mm cable 200m: 17.2W; 400m: 8.4W; 600m: 5W
Reference conditions Guide uses 1m Cat5e camera cable; values depend on two-wire quality/resistance and are not guaranteed endpoint budgets
Physical and environment
Colour Black
Dimensions (L × W × H) 85.4 × 47.1 × 23mm
Weight 200g
Operating temperature −20°C to +60°C

What's in the Box

1 × Wantec 5720 switch-side adapter
1 × 56V DC / 65W power adapter
Quick installation guide

What Will Not Work

A complete two-wire link using this adapter alone; the receiver is separately required.
Assuming 600m reach guarantees full PoE power or a 200Mbps RJ45 connection.

Frequently Asked Questions

Is the remote receiver in this package?
No. This is the switch-side 5720 with its power adapter. The guide pairs it with separately required device-side 5722.
How much power is available at 600m?
The guide’s 22AWG/0.6mm reference gives 5W at 600m, with a 1m Cat5e camera lead. Cable resistance and quality affect the result; this is not a full-power PoE guarantee.
Why does the series mention 200Mbps?
That is the manufacturer’s E-Series line transport reference. The exact unit’s Ethernet interface is 10/100Mbps, so do not treat 200Mbps as its RJ45 port rate.
Singular Expert Insight
Start with endpoint power consumption and the existing wire gauge, then check length. A long route can carry data while leaving too little power for the intended camera or access point; choose the receiver and power arrangement together. Browse IP cameras; check their PoE requirements

Buyer’s Guide

Buy it if

You have a suitable two-wire route and have verified the receiver, cable and endpoint power budget.

Skip it if

You need a complete paired kit, Gigabit Ethernet or guaranteed full PoE power at 600m.

Also consider

The separately required 5722 receiver and a shorter or lower-resistance route when endpoint power demand is higher.
