Zebra ZE521 Right-Hand 6-inch Print Engine, 300 dpi, Thermal Transfer & Direct Thermal, Ethernet, USB, Serial & Bluetooth 4.1

Brand:
Zebra
Zebra ZE521 ZE52163-R0E0000Z Right-Hand Print Engine
Zebra ZE521 Right-Hand 6-inch Print Engine, 300 dpi, Thermal Transfer & Direct Thermal, Ethernet, USB, Serial & Bluetooth 4.1
€7106.88 inc. VAT
Buy
ZE52163-R0E0000Z
€5,972.17
€7,106.88 inc. VAT
Ships from EU stock: 2 item(s)
+ −
Add to wish list Ask a question
Product Code
CB33662
EAN Code
5715063009413
Manufacturer
Zebra
Features
Bluetooth

Quick Specs

Configuration
Right-hand print engine
Resolution / width
300 dpi / 168 mm
Maximum speed
Up to 305 mm/s
Interfaces
Ethernet, USB, Serial, BT 4.1
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Zebra ZE521 6-inch 300 dpi Right-Hand Print Engine

Right-hand print engine300 dpi / 168 mmUp to 305 mm/sEthernet, USB, Serial, BT 4.1

The ZE52163-R0E0000Z is a right-hand 6-inch print engine for integration into industrial print-and-apply equipment. Its 300 dpi head prints labels up to 168 mm wide at speeds up to 305 mm/s. It supplies the printing stage of an automated labelling system; the external applicator, label supply/rewind arrangement and control integration must be provided by the system builder. This configuration includes wired Ethernet, USB, Serial, Bluetooth 4.1 and dual USB Host, with a colour touch screen for local operation.

Before you order:
Confirm right-hand orientation, mechanical mounting, applicator signals and media path with your integrator. This is not a complete desktop label printer or an included label applicator. Wi-Fi, Parallel and RFID encoding are optional upgrades and are not supplied in this SKU.

What's in the Box

  • ZE521 right-hand 300 dpi print engine.
  • EU and UK power cables.

What It Means in Practice

  • In a packing line, the host sends the label format and variable data; the engine prints and presents the label while the integrated external applicator handles its placement on the item.
  • Use thermal transfer media with a matching ribbon for ribbon-based printing, or suitable heat-sensitive stock for direct thermal printing. Qualify the actual supplies and settings on the line.
  • The 168 mm print width suits wide labels. Check liner width separately: the supported media width is 76–180 mm.

What Will Not Work

  • It does not provide automatic application to a product without external applicator equipment and integration.
  • The right-hand configuration cannot be substituted for a left-hand engine without checking the installation.
  • This SKU does not include RFID encoding or a Wi-Fi connection.

Key Features


300 dpi for wide label layouts
Print text, graphics and barcodes across a maximum 168 mm print width. The ZE521 300 dpi speed limit is 12 ips / 305 mm/s; the higher ZE511 headline speeds do not apply.

Interfaces for system integration
USB 2.0, RS-232, 10/100 Ethernet, Bluetooth 4.1, dual USB Host and the applicator interface support a planned print-and-apply installation.

Accessible industrial hardware
All-metal construction, a quick-release printhead and front-access rollers help maintenance within an integrated machine. The 4.3-inch colour touch screen rotates for the installation.

Link-OS and Print DNA
Setup and management tools support configuration, security and remote monitoring. Some Print DNA features require a licence; optional RFID hardware is a separate upgrade.

Technical Specifications

Identification
Model / MPN Zebra ZE521 / ZE52163-R0E0000Z
EAN 5715063009413
Engine orientation Right-hand
Printing
Print methods Thermal transfer / direct thermal
Resolution 300 dpi / 12 dots/mm
Maximum print width 168 mm
Maximum print speed Up to 12 ips / 305 mm/s at 300 dpi
Maximum continuous length 2540 mm at 300 dpi
Media
Width / thickness 76–180 mm / 0.076–0.305 mm
Media types Continuous, die-cut, black mark
Minimum label and liner length Applicator / tear-off: 76.2 mm with backfeed on, 25.4 mm with backfeed off; rewind loose-loop: 25.4 mm
Sensors Adjustable transmissive, fixed reflective
Ribbon length / width / core 600 m / 76–180 mm / 25.4 mm inside diameter
Electronics and interfaces
Memory 512 MB SDRAM / 512 MB Flash
Fitted interfaces USB 2.0, RS-232, Ethernet 10/100, Bluetooth 4.1, 2 × USB Host, applicator interface
Control panel 4.3-inch colour touch screen, rotatable; real-time clock
NFC Print Touch pairing tag
Languages / direct printing ZPL, ZPL II, PDF Direct
Management Link-OS / Print DNA; some features require a licence
Fonts / graphics Unicode, Swiss 721, expandable A–H and GS, scalable font 0, IBM Code Page 850, downloadable TrueType and custom graphics
Linear barcodes Code 11/39/93/128 A-B-C, UCC, ISBT-128, UPC-A/E, EAN-8/13, UPC/EAN extensions, Plessey, Postnet, Standard/Industrial/Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
2D barcodes Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14/composite, Aztec
Barcode ratios 2:1, 7:3, 5:2, 3:1
Optional equipment Wi-Fi / Bluetooth card, Parallel card, RFID kit, UI extension and mounting kit, extended peel bar
Physical, power and environment
Construction All-metal
Dimensions (W × D × H) 245 × 438 × 300 mm
Weight 17.3 kg
Power input 90–264 VAC, 47–63 Hz, power-factor correction
Operating temperature / humidity 0–40 °C / 20–95% RH, non-condensing
Storage temperature / humidity −40–71 °C / 5–95% RH, non-condensing
Compliance ENERGY STAR; CE; IEC 62368-1; EN 55032 Class A; EN 55035; EN 61000-3-2 / 3-3
Verified included items Print engine, EU/UK power cables

Frequently Asked Questions

Is this a complete automatic labelling machine?
No. It is the print engine. A suitable external applicator, media handling system, mounting and control integration are needed to create a complete print-and-apply machine.
Which orientation and print width does this SKU provide?
ZE52163-R0E0000Z is the right-hand ZE521 with a 300 dpi head, 168 mm maximum print width and 76–180 mm media width. Confirm the direction and mounting with the machine integrator.
Does it include Wi-Fi or RFID?
No. The supplied communications include Ethernet, USB, Serial, Bluetooth 4.1 and dual USB Host. Wi-Fi and UHF RFID encoding are available through optional hardware.
Singular Expert Insight
Choose the engine around the applicator installation first: right-hand orientation, label path and signal integration matter as much as resolution. This 6-inch model is appropriate when a 4-inch print width is insufficient. Compare label printers at Singular.

Buyer’s Guide

✓

Buy it if

 Your integrator needs a right-hand, 300 dpi, 168 mm print engine for a production line.
✕

Skip it if

 You need a complete desktop printer or a ready-to-use label applicator.
→

Also consider

 A left-hand engine for a different media path, or an RFID configuration if encoding is required.
Ask Singular to check your media, software and required configuration before ordering.
