Zebra DS3678-HP | Ultra-Rugged Cordless 2D Imager | High Performance | Bluetooth 4.0 | FIPS | (Scanner Only)

The Zebra DS3678-HP is the High Performance variant of the 3600 Ultra-Rugged Series 2D cordless scanner — combining a more powerful imaging engine with FIPS 140-2 encrypted Bluetooth 4.0, reading any 1D or 2D barcode from contact to 2.1 metres with 30% more working range than comparable models. Where the DS3678-SR covers standard-range warehouse and retail scanning, the HP is specified for operations that need to read codes at arm's length and beyond — pallet labels, overhead barcodes, and items behind glass or at distance on shelving. The DS3678-HP2F003VZWW is a scanner-only configuration with vibration motor; cradle, cable, and power supply are sold separately.

High Performance 2D Imager — Reads to 2.1 Metres

The DS3678-HP uses a High Performance 2D area imager that captures any 1D and 2D barcode — Code 128, QR Code, Data Matrix, PDF417, GS1 DataBar, and all standard symbologies — from near-contact to 2.1 metres (7 feet). Screen-displayed barcodes on mobile devices, digital coupons, and e-tickets are read as reliably as printed labels. Zebra claims 30% more working range than similar models in this class, which translates to fewer positioning adjustments in aisle, at the dock door, or on the production floor. The PRZM Intelligent Imaging engine ensures rapid decode even on damaged, poorly printed, or low-contrast labels at extended distances.

FIPS 140-2 Bluetooth 4.0 & Wi-Fi Friendly Mode

The 2F in the DS3678-HP2F003VZWW SKU denotes FIPS 140-2 compliance — all Bluetooth 4.0 BLE communication is encrypted to the US federal cryptographic standard, preventing interception of scan data in transit. This is required for US government procurement and common in defence logistics, regulated pharmaceutical operations, and secure healthcare environments. Additionally, the DS3678-HP includes Zebra's Wi-Fi Friendly Mode, which coordinates Bluetooth transmission timing to eliminate interference with co-located Wi-Fi networks — a practical advantage in warehouse and retail environments with dense 802.11 infrastructure where standard Bluetooth can degrade Wi-Fi throughput.

Ultra-Rugged 3600 Series Construction

The DS3678-HP shares the full 3600 Ultra-Rugged platform: IP67 rated (dust-proof, submersible to 1 metre for 30 minutes), surviving 8 ft (2.4m) drops to concrete and 5,000 tumble cycles — Zebra states 23% greater durability than any other scanner in its class. The operating temperature range of -20°C to 50°C covers cold storage, outdoor dock-door environments, and hot manufacturing areas. The industrial green and black colour scheme marks it as part of the 3600 Ultra-Rugged Series, a visual standard in enterprise warehouse operations. The scanner is compatible with Zebra's CR3678 cradle range for both charging and communication.

PowerPrecision+ Battery — 100,000+ Scans Per Charge

The DS3678-HP is powered by Zebra's PowerPrecision+ 3100 mAh Lithium-Ion battery, delivering over 100,000 scans per full charge — enough to sustain multiple back-to-back shifts without interruption. This represents 56% more scans-per-charge than competitive scanner batteries. PowerPrecision+ delivers real-time battery intelligence: charge level, charge cycles consumed, current capacity, and a State of Health indicator are all accessible through Zebra's management tools, enabling proactive battery replacement before failures affect operations. The battery is user-replaceable for hot-swapping without tools.

Vibration Motor & Triple Good-Read Feedback

The DS3678-HP2F003VZWW includes a vibration motor (V suffix), providing tactile confirmation alongside the audible beeper and LED indicators. In high-noise environments — noisy docks, manufacturing lines, or areas requiring hearing protection — the vibration motor delivers unambiguous scan confirmation without relying on audio. Bluetooth range extends to 300 feet (91 metres), giving operators significant freedom of movement from the charging cradle. The scanner is configurable via Zebra's 123Scan utility for interface parameters, symbology settings, and feedback preferences without specialist hardware.

Frequently Asked Questions

What is the difference between the DS3678-HP and DS3678-SR?

Both share the same 3600 Ultra-Rugged platform (IP67, 2.4m drops, PowerPrecision+ battery). The HP (High Performance) variant uses a more powerful 2D imager that reads to 2.1 metres with 30% more working range than the SR (Standard Range). Choose the HP for applications where reading distance matters — pallet labels, overhead codes, or items behind glass. The DS3678-HP2F003VZWW also adds FIPS 140-2 encrypted Bluetooth, which the standard SR does not include.

What cradle is compatible with the DS3678-HP2F003VZWW?

This scanner-only SKU requires a separately purchased cradle. Compatible options include the Zebra CR3678 series single-slot cradles (USB, RS-232, or charge-only variants). Ensure the cradle purchased is the FIPS-compatible version if your procurement requires end-to-end FIPS 140-2 compliance. Contact Zebra or your reseller for the correct cradle part number for your environment.

What does Wi-Fi Friendly Mode do?

Wi-Fi Friendly Mode coordinates the timing of Bluetooth transmissions to avoid colliding with Wi-Fi channel usage. In dense wireless environments — warehouse Wi-Fi grids, retail store networks — standard Bluetooth can interfere with 802.11 throughput. Wi-Fi Friendly Mode eliminates this interference, allowing the DS3678-HP to co-exist with Wi-Fi infrastructure without degrading network performance or scan reliability.

Does the DS3678-HP read barcodes on screens?

Yes. The HP 2D imager reads barcodes displayed on backlit screens — smartphones, tablets, digital coupons, e-tickets, and mobile boarding passes — with the same reliability as printed labels. The PRZM Intelligent Imaging engine handles glare and varied pixel densities without manual focus adjustment.
