Zebra ZT231 Industrial Direct Thermal Label Printer, 203 dpi, Passive Peeler, 4.3-inch Touchscreen, USB, Ethernet and Serial
Brand:
Zebra
Zebra ZT231 Industrial Direct Thermal Label Printer, 203 dpi, Passive Peeler, 4.3-inch Touchscreen, USB, Ethernet and Serial
€1053.73 inc. VAT
ZT23142-D1E000FZ
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Zebra ZT231 203 dpi Direct Thermal Peeler Printer
203 dpiDirect thermalPassive peelerNo liner take-up
The Zebra ZT23142-D1E000FZ is a 203 dpi direct thermal industrial label printer with a front-mounted passive peeler. It separates each label from its backing for application, but does not include a spindle to collect the spent liner. A 4.3-inch colour touchscreen and wired USB, USB Host, Ethernet and RS-232 support a fixed labelling station. This SKU prints heat-sensitive media without ribbon; Wi-Fi is not included.
Before you order:
Choose suitable direct thermal labels and confirm the peel-mode minimum label/liner length of 13 mm. Route and manage the spent backing externally; passive peel is different from liner take-up. Validate your software/driver or ZPL/EPL workflow. BTLE is documented for location functionality, not ordinary Bluetooth label printing.
What's in the Box
- One Zebra ZT231 printer with passive peeler, ZT23142-D1E000FZ
- EU and UK power cords
What It Means in Practice
- For example, load a suitable direct thermal roll, connect a workstation by USB or Ethernet, and send the shipping label from compatible software. The printer creates the label; your application controls order and stock data.
- Thread the backing through the fitted peel path, print from compatible software, then take the separated label and apply it to the item. Provide a safe collection route for the loose backing because this configuration has no take-up spindle.
- Up to 305 mm/s is the 203 dpi engine maximum. Label format, media and settings affect actual throughput.
What Will Not Work
- Thermal-transfer ribbons cannot be used with this direct-thermal-only SKU.
- Wi-Fi, automatic cutting, liner take-up and RFID encoding are not included.
Key Features
203 dpi industrial output
Prints up to 104 mm wide at up to 305 mm/s, with a metal frame and enclosure for light industrial use. The passive peel path presents labels without collecting the liner.
Touchscreen control
The 4.3-inch resistive colour touchscreen provides status and setup tools. The bi-fold door and side-loading path make rolls accessible.
Wired label station
USB, USB Host, serial and 10/100 Ethernet are installed. ZPL/ZPL II and EPL/EPL2 on this 203 dpi model support compatible label applications.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Choose passive peel for applying labels one at a time at a wired station. Check operator access and backing disposal alongside label size and media life. If you need contained liner collection, specify the factory take-up configuration instead. Compare label printers and handling configurations
Buyer’s Guide
✓
Buy it if
you need wired 203 dpi direct thermal labels presented by passive peel.✕
Skip it if
you need ribbon printing, included Wi-Fi, a cutter or liner take-up.→
Also consider
factory liner take-up if backing collection is essential, or tear-off when labels should remain on their liner.BTLE is provided for location-related functionality; it is not specified here as a Bluetooth printing interface. The installed Wi-Fi card is the global version excluding the US, Canada and Japan.
Features - Zebra - ZT23142-D1E000FZ
Colour
black
Interface
- USB2.0,
- Ethernet
More Details
Product Code
CF07521
EAN Code
0663056023999
Manufacturer
Zebra
