Datalogic Gryphon GD4520 High Density 1D/2D Scanner, USB Cable Kit, Black, Stand Separate

Brand:
Datalogic
Datalogic Gryphon GD4520 High Density Black 2D USB Kit
Datalogic Gryphon GD4520 High Density 1D/2D Scanner, USB Cable Kit, Black, Stand Separate
€361.27 inc. VAT
Buy
GD4520-BKK1-HD
€303.59
€361.27 inc. VAT
Ships from EU stock: 20 item(s)
+ −
Add to wish list Ask a question
Product Code
04:518427
EAN Code
5706998972347
Manufacturer
Datalogic

Quick Specs

Focus
High Density · small codes
Reading
1D/2D · 1280 × 800
Connection
Corded · USB-only
Package
Scanner + USB cable · no stand
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

High-density reading for smaller labels, with USB cable included

High Density1D/2DUSB kitStand separate

This black GD4520-BKK1-HD kit combines the High Density 1D/2D scanner with a USB host cable. HD optics are intended for smaller, condensed codes: the specified resolution is 3 mil for linear/PDF417 and 4 mil for Data Matrix. This does not mean longer range than Standard Range optics; the HD ranges in the table show the working distances for each code size. The host application handles the meaning of the scanned data.

Before you order:
BKK1-HD includes scanner and USB cable 90A052258. A stand or All-in-One permanent base is not included. GD4520 is USB-only; GD4590 offers other host interfaces. HD is a different optical focus from SR, so test representative small labels at your working distance.

What's in the Box

  • Black GD4520 High Density scanner
  • USB cable 90A052258

What Will Not Work

  • No Bluetooth, cordless radio or RS232 on this USB-only reader.
  • No stand or permanent base in this kit. HD does not imply Digimarc or DPM capabilities of separate variants.

Key Features


Target the intended code
The four-dot aimer and centre cross help frame the reading zone when several labels are close together.

Flexible working position
Motionix supports transitions between handheld and presentation use without requiring a wireless scanner.

Visible confirmation
Green Spot and two good-read LEDs form the 3GL indication, with an adjustable audible signal.

Technical Specifications

Identification
SKU GD4520-BKK1-HD
EAN 5706998972347
Included Black GD4520 High Density scanner + USB cable 90A052258; stand separate
Engine and reading
Sensor 1 MP, 1280 × 800 pixels
Formats Standard 1D and GS1 DataBar; QR/Micro QR, Data Matrix, Aztec, Han Xin, MaxiCode; postal; PDF417/MicroPDF417 and composite/stacked codes
Display reading Supported
Mode switching Motionix handheld/presentation sensing
Illumination / aiming Warm white / 650 nm red laser, 4-dot + centre cross
Motion / contrast 35 IPS / minimum 15%
Reading angles Pitch ±65°, skew ±65°, roll 360°
HD resolution 1D / PDF417 3 mil / 0.077 mm; Data Matrix 4 mil / 0.102 mm
Feedback Green Spot, dual good-read LEDs (3GL), adjustable beeper
Image capture BMP / JPEG / TIFF; 256, 16 or 2 greyscale levels
Typical HD reading depth
Code39 3 mil 5.0–15.0 cm
Code39 5 mil 0.5–25.0 cm
Data Matrix 5 mil 5.5–9.0 cm
Data Matrix 10 mil 2.0–27.0 cm
EAN-13 7.5 mil 2.0–23.5 cm
EAN-13 13 mil 1.0–40.0 cm
PDF417 4 mil 3.0–12.0 cm
PDF417 10 mil 0.5–31.0 cm
QR 10 mil 2.0–25.0 cm
Conditions Depends on symbol length, angle, print resolution, contrast and ambient light
Power and construction
Interface / supply USB-only / 5 VDC
Current at 5 V Operating below 300 mA; idle below 90 mA
Dimensions / weight 166 × 68 × 109 mm / 161 g reader
Colour Black
Sealing / repeated drops IP52 / 1.8 m onto concrete
Temperature Operating 0–50 °C; storage −40–70 °C
Humidity / light / ESD 0–95% non-condensing / 0–100000 lux / 16 kV air
Compliance EU/China RoHS; IEC 60825 Class 2 aiming laser
Utilities Aladdin, OPOS, JavaPOS, remote host download
Manufacturer term 5-year factory warranty; seller terms separate

Frequently Asked Questions

How is HD different from SR?
HD targets smaller, condensed codes. For example, its typical EAN-13 13 mil range is 1.0–40.0 cm, while SR is 1.0–71.0 cm under the sheet conditions. Choose the focus for label size and working distance, not the HD name alone.
Does the kit include a stand?
No. It includes the black HD scanner and USB90A052258 cable. A stand must be ordered separately.
Does Motionix make it wireless?
No. Motionix switches scanning modes as the reader is handled. Data and power remain on the USB cable.
Singular Expert Insight
Choose HD for genuinely small labels and verify them at the intended distance. For ordinary retail labels where reach matters more, compare SR. This cable-inclusive kit is ready for a USB host connection but requires a separate support if you want a fixed presentation position. Compare scanner kits and connections

Buyer’s Guide

✓

Buy it if

 You need USB reading of dense 1D/2D labels with the cable included.
✕

Skip it if

 You expect a stand, cordless mobility or maximum SR reach.
→

Also consider

 SR optics for ordinary labels at longer distances, or an explicitly stand-inclusive kit.
Tell us your host and barcode samples to check the engine and interface requirements.
